Neuron 7

Out of stock

2.549 €

The flagship of the aluminium Neuron range. Get the ultimate combo of long-distance comfort and efficiency, trail-ready full-suspension design, and alloy toughness.

Front Fork Travel: 140 mm
Weight: 13,6 kg

All components

Customer reviews (94)

Press and awards (2)

Product Configuration

Colour:

Forest Green

Members only product.

Frame Size:

Members only product.

Buying reasons

Klarna offers direct payments, pay later options, or installment plans
Calculate amount
We ship direct to your local bike shop. They build it, you pick it up ready to ride.
How to choose Collect & Ride

Delivery: Select batch number

2.549 €

Product added to cart

Highlights Neuron 7

Components

All components are based on size M

Frame

Frame
- Canyon Neuron
- Rugged full-suspension aluminium MTB frame with a perfectly balanced geometry for a confidence inspiring ride.
- Axle dimension 12x148 mm
- Material Aluminium (AL)
- Weight 1,620 g
Rear Shock
- FOX Float DPS Performance
- Weight 459 g
Suspension Fork
- FOX 34 Float Performance GRIP
- Axle dimension 15x110 mm
- Stanchion Diameter 34 mm
- Travel 140 mm
- Fork steer tube diameter 1 1/8" - 1,5"
- Offset 44 mm
- Volume Spacer Oe 1
- Weight 640 g
Seatpost Clamp
- Canyon SC0001

Drivetrain

Rear Derailleur
- Shimano Deore XT M8100
- Cage length long
- Weight 282 g
Shift Lever
- Shimano Deore XT SL-M8100
- Weight 130 g
Cassette
- Shimano Deore XT CS-M8100
- Number of sprockets 12
- Range 10-51 12S
Crank
- Shimano Deore XT M8120
- Number of chainrings 1
Bottom bracket
- Shimano BSA BB52
- Bottom bracket standard BSA HT2 68/73
- Weight 98 g
Chain
- Shimano Deore M6100

Brakes

Disc Brake
- Shimano SLX M7120
Disc Brake
- Shimano SLX M7120
Brake Rotor
- Shimano Ultegra RT-CL800
- Size 180 mm
- Weight 145 g

Wheels

Front Wheel
- DT Swiss M 1900
- Axle dimension 15x110 mm
- Rotor mount Center Lock
- Rim height 20 mm
- Weight 972 g
Rear Wheel
- DT Swiss M1900
- Axle dimension 12x148 mm
- Rotor mount Center Lock
- Rim height 20 mm
- Weight 1,133 g
Tyre
- Schwalbe Nobby Nic 29x2.4" bronze skin
- Width 2.4"
- Weight 876 g
Tyre
- Schwalbe Wicked Will 29x2.4" bronze skin
- Width 2.4"
Thru Axle
- Canyon Quixle Through Axle QR 148x12
- Axle dimension 12x148 mm

Cockpit

Stem
- Iridium Stem
- Fork steer tube diameter 1 1/8"
Handlebar
- Iridium Flatbar
- Material Aluminium
- Rise 5 mm
Grips
- Ergon GA20

Seat

Saddle
- Ergon SM10
- Gender Male
- Weight 320 g
Seatpost
- Canyon SP0081
- Seatpost diameter 30,9 mm
- Material Aluminium (AL)
- Weight 622 g

Light

Lights
- Reflector Set

Accessories

Pedals
- None included
Manuals and Accessories
- Canyon Organza Bag
Manuals and Accessories
- Canyon Assembly Paste
Manuals and Accessories
- Canyon Torque Wrench
Manuals and Accessories
- Quick Start Guide
Manuals and Accessories
- Canyon Shock Pump 300 Psi
Manuals and Accessories
- Smallbox

Content is loading

Geometry & dimensions

Basic geometry

Detailed geometry table
Frame size
Body Height in cm	≤ 166	166 - 175	175 - 183	183 - 192	≥ 192
a Seat Height in mm	612 - 766	637 - 816	692 - 891	727 - 926	767 - 966
b Seat Tube Length in mm	390	390	425	460	500
c Top Tube Length in mm	556	579	611	639	674
d Head Tube Length in mm	90	100	110	125	143
e Head Tube Angle	66°	66°	66°	66°	66°
f Seat Tube Angle	76°	76°	76°	76°	76°
g Chainstay Length in mm	430	430	440	440	440
h Wheel Base in mm	1.139	1.164	1.203	1.234	1.271
i Stack in mm	587	596	626	639	656
j Reach in mm	410	430	455	480	510
k Stand-over Height in mm	756	760	760	766	772
l Bottom Bracket Offset in mm	18	18	38	38	38

Component geometry

Detailed geometry table
Frame size
Spacer in mm	10,0	10,0	15,0	15,0	15,0
Stem Length in mm	50	50	50	50	50
Handlebar Width in mm	740	740	760	760	760
Crank Length in mm	165,0	165,0	170,0	170,0	170,0
Chainring Size	30	30	30	30	30
Seat Post Diameter in mm	30,9	30,9	30,9	30,9	30,9
Dropper post travel in mm	125	150	170	170	170
Seat Post Length in mm	408	458	498	498	498
Maximum Seat Post Insertion Depth in mm	234	259	279	279	279
Minimum Seat Post Insertion Depth in mm	80	80	80	80	80
Wheel Size	27.5"	27.5"	29"	29"	29"
Disc Size in mm	180 / 180	180 / 180	180 / 180	180 / 180	180 / 180
Front Fork Travel in mm	140	140	140	140	140
Fitting Length	190X45	190X45	210X50	210X50	210X50
Rim height in mm	20	20	20	20	20

Download PDF

Press and awards

2023

Tipp Testsieger

The bike feels beautifully balanced and controlled right from the first turn turn of the crank.

Award

The bike feels beautifully balanced and controlled right from the first turn turn of the crank.
2024

Bike Of The Year

The Neuron is rightly a real all-time favorite.

Award

The Neuron is rightly a real all-time favorite.

Content is loading

Neuron 7 support

Bike classification

This category also covers the requirements of categories 1-2. In addition it includes use on harsher, unpaved terrain. The scope for these bikes includes occasional jumps up to a maximum height of 60 cm. Jumps of this scale can cause inexperienced riders to have accidents on landing, which can result in injury. Hardtail mountain bikes and full-suspension bikes with short travel are included in this category.

Disclaimer

Subject to technical modification without notice. Errors and omissions excepted.
