Aeroad CFR eTap
-
Weight:
7.24 kg
WeightWeight is based on a size medium frame.
- Material: Carbon (CFR)
- Colour: CFR Stealth
-
-
Members only product. Log in here
Highlights Aeroad CFR eTap
Premium finish
A pro-level cockpit
A durable aero seatpost
Aerodynamically optimised fork
Frame
-
Frame
- Canyon Aeroad CFR Disc
- Canyon Factory Racing R065 aero carbon frame, featuring ultra-rare Toray M40X carbon fibres. Shaped by extensive computational fluid dynamics analysis, validated in the wind tunnel. Fully internal routing, flat-mount disc standard. Weight: 915 g
- Axle dimension: 12x142 mm
- Tyre clearance: 31 mm
- Material: Carbon (CFR)
- Weight: 1,250 g
-
Fork
- Canyon FK0060 CF Disc
- Fork with aero design shaped using advanced CFD technology. Disc flat-mount disc standard. CT scanner tested and approved.
- Axle dimension: 12x100 mm
- Fork steer tube diameter: 1 1/8"
- Tyre clearance: 31 mm
- Material: Carbon (CF)
- Weight: 430 g
Drivetrain
-
Battery
- SRAM Powerpack
-
Rear Derailleur
- SRAM RED eTap AXS 12s
- Weight: 280 g
-
Front Derailleur
- SRAM RED eTap AXS
- Weight: 170 g
-
Cassette
- SRAM RED XG-1290, 12-speed, 10-28
- Number of sprockets: 12
-
Crank
- SRAM RED AXS Powermeter
- Number of chainrings: 2
-
Bottom bracket
- SRAM DUB Pressfit
- Bottom bracket standard: PF 86,5
- Weight: 67 g
-
Chain
- SRAM Red D1 12-speed
- Premium 12-speed chain. Signature flat-top design enables a narrower design with quieter operation and increased strength and durability. With HollowPin construction and hard chrome plated inner link plates and rollers for reduced wear and prolonged life.
Brakes
-
Shift-/ Brake Lever
- SRAM RED eTap AXS HRD, 12-speed
- Weight: 310 g
-
Shift-/ Brake Lever
- SRAM RED eTap AXS HRD, 12-speed
- Number of pistons: 2
- Weight: 610 g
-
Brake Rotor
- SRAM Centerline X
- Size: 160 mm
- Weight: 130 g
Wheels
-
Front Wheel
- Zipp 454 NSW TL Hookless
- Axle dimension: 12x100 mm
- Rotor mount: Center Lock
- Rim height: 58 mm
- Inner width: 23 mm
- Rim material: Carbon
- Weight: 631 g
-
Rear Wheel
- Zipp 454 NSW TL Hookless, XDR
- Axle dimension: 12x142 mm
- Rotor mount: Center Lock
- Rim height: 58 mm
- Inner width: 23 mm
- Rim material: Carbon
- Weight: 727 g
-
Tyre
- Continental GP 5000 S TR
- Width: 28 mm
- Weight: 283 g
-
Thru Axle
- DT Swiss Through Axle
- Axle dimension: 12x100 mm
-
Thru Axle
- DT Swiss Through Axle
- Axle dimension: 12x142 mm
Cockpit
-
Cockpit
- Canyon CP0018 Aerocockpit
- Aero design, reinforced carbon walls for added stiffness and improved durability.
- Material: Carbon (CF)
- Weight: 195 g
-
Handlebar Tape
- Canyon Ergospeed Gel
- Grippy, durable bar tape with a premium, high-quality, comfortable feel.
- Color: black
Seat
-
Saddle
- Fizik Vento Argo R3 Adaptive 140mm
- Gender: Unisex
- Weight: 224 g
-
Seatpost
- Canyon SP0046 Aero Seatpost
- Aero-optimised carbon seatpost with new sleeve bearing that creates a seal and reduces seatpost and seat tube friction and prevents dirt from entering.
- Clamp diameter: 27,2 mm
-
Seat Clamp
- Canyon GP0223-02 Clamp Set 7x7
Accessories
-
Pedals
- None included
-
Manuals and Accessories
- Canyon Organza Bag
-
Manuals and Accessories
- Canyon Assembly Paste
-
Manuals and Accessories
- Canyon Starter Box
-
Manuals and Accessories
- Canyon Torque Wrench
-
Manuals and Accessories
- Endurace Quick Start Guide
Body Height in cm
|
≤ 166 | 166 - 172 | 172 - 178 | 178 - 184 | 184 - 190 | 190 - 196 | ≥ 196 |
---|---|---|---|---|---|---|---|
Seat Height in mm
(a)
|
624 - 704 | 654 - 734 | 684 - 764 | 714 - 794 | 744 - 824 | 774 - 854 | 804 - 884 |
Seat Tube Length in mm
(b)
|
443 | 473 | 503 | 533 | 563 | 593 | 623 |
Top Tube Length in mm
(c)
|
520 | 533 | 549 | 559 | 572 | 598 | 613 |
Head Tube Length in mm
(d)
|
86 | 106 | 126 | 147 | 167 | 193 | 211 |
Head Tube Angle
(e)
|
70,5° | 71,5° | 72,75° | 73,25° | 73,25° | 73,5° | 73,75° |
Seat Tube Angle
(f)
|
73,5° | 73,5° | 73,5° | 73,5° | 73,5° | 73,5° | 73,5° |
Chainstay Length in mm
(g)
|
410 | 410 | 410 | 410 | 410 | 410 | 410 |
Wheel Base in mm
(h)
|
971 | 976 | 984 | 989 | 1.002 | 1.025 | 1.038 |
Stack in mm
(i)
|
498 | 521 | 539 | 560 | 580 | 606 | 624 |
Reach in mm
(j)
|
372 | 378 | 390 | 393 | 401 | 419 | 429 |
Stand-over Height in mm
(k)
|
733 | 759 | 785 | 810 | 834 | 860 | 884 |
Bottom Bracket Offset in mm
(l)
|
72 | 70 | 70 | 72 | 70 | 70 | 70 |
Stack+ in mm
|
573 | 596 | 613 | 635 | 656 | 681 | 701 |
Reach+ in mm
|
429 | 446 | 459 | 473 | 490 | 509 | 529 |
Spacer in mm
|
15,0 | 15,0 | 15,0 | 15,0 | 15,0 | 15,0 | 15,0 |
---|---|---|---|---|---|---|---|
Cockpit Dimensions in mm
|
80-390 | 90-390 | 90-390 | 100-410 | 110-410 | 110-410 | 120-410 |
Crank Length in mm
|
165,0 | 170,0 | 172,5 | 172,5 | 175,0 | 175,0 | 175,0 |
Chainring Size
|
48/35 | 48/35 | 48/35 | 48/35 | 48/35 | 48/35 | 48/35 |
Seat Post Length in mm
|
335 | 335 | 335 | 335 | 335 | 335 | 335 |
Maximum Seat Post Insertion Depth in mm
|
202 | 202 | 202 | 202 | 202 | 202 | 202 |
Minimum Seat Post Insertion Depth in mm
|
122 | 122 | 122 | 122 | 122 | 122 | 122 |
Wheel Size
|
28" | 28" | 28" | 28" | 28" | 28" | 28" |
Disc Size in mm
|
140 / 140 | 160 / 160 | 160 / 160 | 160 / 160 | 160 / 160 | 160 / 160 | 160 / 160 |
Aeroad CFR eTap support
Other riders also bought
Bike classification
Bikes of this category are designed for riding on hard-surface roads where the wheels remain in permanent contact to the ground. These are in general road racing bicycles with racing handlebars or straight handlebars, triathlon or time trial bicycles. The permissible maximum overall weight comprising rider, luggage and bicycle should not exceed 120 kg. Under certain circumstances this permissible maximum weight can be further limited by the component manufacturers’ recommendations for use. Proven cyclocross and gravel bikes with racing handlebars and cantilever or disc brakes are a special case in this category. In addition, these bikes are also suitable for gravel paths and off-road trails where a short loss of tyre contact with the ground due to small stairs or steps at a height of 15 to 20 cm can occur.
Disclaimer
Subject to technical modification without notice. Errors and omissions excepted.
