Outlet Road Outlet

Ultimate CFR Di2

Name: Ultimate CFR Di2
Brand: Canyon
Price: 7669.00 USD
Availability: OutOfStock
Rating: 5 (20 reviews)

Refurbished bike in XL
-16%

6,619 US$

Original price ~~7,849 US$~~

You save 1,230 US$

CFR- World-class carbon frame construction
Pro-proven Shimano Dura-Ace Di2 electronic shifting
Shimano Dura-Ace Power Meter
DT Swiss ARC 1100 carbon wheels

Material: Carbon (CFR)
Weight: 6.76 kg

Customer reviews (20)

Colour: Sparkle Stealth

Members only product.

Frame Size: XL

Select your model

Delivery within 3-10 working days

Only 1 left in stock

Attention: It is not always possible to show all signs of wear. You should expect other scratches, paint damage and/or signs of use. Pricing is adjusted according to the wear class (light, medium or heavy signs of use).

Members only product.

6,619 US$

Original price ~~7,849 US$~~

You save 1,230 US$

Delivery within 3-10 working days

Only 1 left in stock

Additional information

Current delivery times information. Read more

Not included:

Your bike already arrives 95% built. We give you the tools. And simple instructions. No technical skills needed.
That’s our quality promise – if you’re not 100% happy with your bike, we’re not happy either.
Learn more
That’s our quality promise – if you’re not 100% happy with your bike, we’re not happy either.

Delivery within 3-10 working days

Highlights Ultimate CFR Di2

Peloton-proven performance

Ready for the mountains

Effortlessly ascend the steepest climbs with the Ultimate CFR Di2. Super lightweight, our finest carbon frame is equipped with premium components to deliver a memorable ride. Uphill, downhill, on the flats, this bike delivers.

Canyon Factory Racing

Canyon Factory Racing (CFR) is our advanced development programme, a relentless push for the next level of ride performance. We combine meticulous German engineering with a ‘no compromises’ approach to innovation. The result? Bikes that win.

Designing the new Ultimate

Canyon engineer, Lukas Birr, explains the design and development process that went into creating the Ultimate; a road bike that delivers the perfect balance. Lightweight, stiff and aerodynamic. This is our classic road race bike, evolved.

Technology

Featherweight frame

The Ultimate boasts one of the lightest frames on the WorldTour. More impressive yet, that light weight doesn’t come at a sacrifice to aerodynamics, comfort or durability.

Years of setting the pace

The Ultimate is the bike of choice for racers around the world, more than 20 years since its debut. Why? Because it balances timeless aesthetics with ultralight, aero-optimised performance. It is the modern classic.

Light, stiff, and aero

A lightweight bike isn’t groundbreaking. A stiff bike isn’t going to shatter expectations. A bike that’s aero optimised? It’s a given. Making one bike that perfectly embodies all these traits? That’s an entirely different—and breathtaking—feat of engineering. It’s also what makes this the ultimate racing machine.

Components

Frame

Frame
- Canyon Ultimate CFR
- Pro-level build of our latest 5th-generation Ultimate frame delivering the pinnacle of stiffness-to-weight. As raced at World Tour level.
- Axle dimension 12x142 mm
- Tyre clearance 33 mm
- Material Carbon (CFR)
- Weight 780 g
Fork
- Canyon FK0108 CFR
- Superlight carbon fork, engineered for maximum stiffness-to-weight and compliance.
- Axle dimension 12x100 mm
- Fork steer tube diameter 1 1/4"
- Tyre clearance 33 mm
- Material Carbon (CFR)
- Weight 376 g
Seatpost Clamp
- Canyon GP0224-02 Adapter seatstay 7x9

Drivetrain

Battery
- Shimano BT-DN300 Di2 Battery
Rear Derailleur
- Shimano Dura-Ace Di2 RD-R9250, 12-speed
- Cage length medium
- Weight 256 g
Front Derailleur
- Shimano Dura-Ace Di2 FD-R9250
- Weight 96 g
Cassette
- Shimano Dura-Ace R9200, 12-speed, 11-34
- Number of sprockets 12
- Range 11-34
Crank
- Shimano Dura-Ace Di2 Powermeter 172.5mm
- Number of chainrings 2
Bottom bracket
- Shimano Pressfit BB92
- Bottom bracket standard PF 86,5
- Weight 55 g
Chain
- Shimano XTR

Brakes

Shift-/ Brake Lever
- Shimano Dura-Ace Di2 R9270, 12-speed
- Number of pistons 2
- Weight 332 g
Shift-/ Brake Lever
- Shimano Dura-Ace Di2 R9270, 12-speed
- Number of pistons 2
- Weight 330 g
Brake Rotor
- Shimano Dura-Ace RT-CL900
- Size 140 mm
- Weight 94 g
Brake Rotor
- Shimano Dura-Ace RT-CL900
- Size 160 mm
- Weight 113 g

Wheels

Front Wheel
- DT Swiss ARC 1100 Dicut db
- Axle dimension 12x100 mm
- Rotor mount Center Lock
- Rim height 38 mm
- Inner width 20 mm
- Rim material Carbon
- Weight 587 g
Rear Wheel
- DT Swiss ARC 1100 Dicut db
- Axle dimension 12x142 mm
- Rotor mount Center Lock
- Rim height 38 mm
- Inner width 20 mm
- Rim material Carbon
- Weight 712 g
Tyre
- Pirelli P Zero Race TLR
- Width 28 mm
- Weight 313 g
Thru Axle
- DT Swiss Through Axle
- Axle dimension 12x100 mm
Thru Axle
- DT Swiss Through Axle
- Axle dimension 12x142 mm

Cockpit

Cockpit
- Canyon CP0018 Aerocockpit
- Aero design, reinforced carbon walls for added stiffness and improved durability.
- Material Carbon (CF)
- Weight 195 g
Handlebar Tape
- Canyon Ergospeed Gel
- Grippy, durable bar tape with a premium, high-quality, comfortable feel.
- Color Black

Seat

Saddle
- Selle Italia SLR Boost 3D KIT Carbonio Superflow
- Width 130 mm
- Gender Unisex
- Weight 163 g
Seatpost
- Canyon SP0064
- Superlight custom carbon seatpost with aerodynamic D-shape profile.
- Setback 0 mm
- Material Carbon (CF)
- Weight 70 g

Light

Lights
- Reflector Set

Accessories

Pedals
- None included
Manuals and Accessories
- Canyon Organza Bag
Manuals and Accessories
- Canyon Assembly Paste
Manuals and Accessories
- Canyon Torque Wrench
Manuals and Accessories
- Quick Start Guide
Manuals and Accessories
- Smallbox

Content is loading

Geometry & dimensions

Basic geometry

Detailed geometry table

Body Height in cm	≤ 166	166 - 172	172 - 178	178 - 184	184 - 190	190 - 196	≥ 196
Seat Height in mm (a)	624 - 724	654 - 754	684 - 784	714 - 814	744 - 844	774 - 874	804 - 904
Seat Tube Length in mm (b)	420	450	480	510	540	570	600
Top Tube Length in mm (c)	516	529	546	555	569	594	610
Head Tube Length in mm (d)	88	107	121	142	162	188	206
Head Tube Angle (e)	70°	71,2°	72,8°	73,25°	73,3°	73,5°	73,8°
Seat Tube Angle (f)	73,5°	73,5°	73,5°	73,5°	73,5°	73,5°	73,5°
Chainstay Length in mm (g)	410	410	410	410	413	415	415
Wheel Base in mm (h)	975	979	982	988	1.003	1.029	1.042
Stack in mm (i)	498	520	539	560	580	606	624
Reach in mm (j)	372	378	390	393	401	419	429
Stand-over Height in mm (k)	720	748	775	801	828	851	874
Bottom Bracket Offset in mm (l)	73	73	73	73	73	73	73
Stack+ in mm	573	596	613	635	656	681	701
Reach+ in mm	428	446	459	473	490	509	530
Effective stack in mm (O): Vertical distance between the bottom bracket and the hand position Learn more	565	592	608	629	651	676	694
Effective reach in mm (P): Horizontal distance between the bottom bracket and the hand position Learn more	522	516	539	553	570	599	610

Component geometry

Detailed geometry table

Spacer in mm	16	16	16	16	16	16	16
Cockpit Dimensions in mm	80-390	90-390	90-390	100-410	110-410	110-410	120-410
Crank Length in mm	170,0	170,0	172,5	172,5	175,0	175,0	175,0
Chainring Size	52/36	52/36	52/36	52/36	52/36	52/36	52/36
Seat Post Length in mm	316	316	316	316	316	316	316
Maximum Seat Post Insertion Depth in mm	160	160	160	160	160	160	160
Minimum Seat Post Insertion Depth in mm	60	60	60	60	60	60	60
Wheel Size	28"	28"	28"	28"	28"	28"	28"
Disc Size in mm	140 / 140	140 / 140	160 / 140	160 / 140	160 / 140	160 / 160	160 / 160
Rim height in mm	38	38	38	38	38	38	38
