Aeroad CF SL 8
-
Colour: Grey In Grey
-
Colour: Alpecin-Deceuninck Replica -
Colour: Morello Red
-
Members only product. Log in here
Highlights Aeroad CF SL 8
Aero for everyone
Balanced geometry
A watt-saving aero cockpit
A light, stiff, aero fork
Frame
-
Frame
- Canyon Aeroad CF SL Disc
- Aero frame with the tube forms and geometry as the flagship Aeroad CFR. Shaped by extensive supercomputer analysis, validated in the wind tunnel.
-
Axle dimension 12x142 mm
-
Tyre clearance 31 mm
-
Material Carbon (CF)
-
Weight 1,009 g
-
Fork
- Fork for R082 Aeroad 700c
- Aerodynamic fork. Shaped and tested by our partner Swiss Side with use of extensive computational fluid dynamics analysis.
-
Fork steer tube diameter 1 1/4"
-
Tyre clearance 31 mm
-
Material Carbon (CF)
-
Weight 750 g
-
Seatpost Clamp
- Canyon GP0223-02 Clamp Set 7x7
-
Seatpost Clamp
- Canyon GP0391-02 Seat Clamp
Drivetrain
-
Rear Derailleur
- Shimano Ultegra R8000 SS
-
Cage length short
-
Weight 210 g
-
Front Derailleur
- Shimano Ultegra R8000
-
Weight 90 g
-
Cassette
- Shimano Ultegra R8000 11-30 11s
-
Number of sprockets 11
-
Range 11-30
-
Crank
- Shimano Ultegra R8000
-
Number of chainrings 2
-
Bottom bracket
- Token Ninja Lite BB4124
-
Bottom bracket standard PF 86,5
-
Weight 85 g
-
Chain
- Shimano CN-HG701 11s
Brakes
-
Brake
- Shimano Flat Mount Adapter +20mm
-
Shift-/ Brake Lever
- Shimano Ultegra R8020 2s
-
Weight 218 g
-
Shift-/ Brake Lever
- Shimano Ultegra R8020 11s
-
Weight 220 g
-
Brake Rotor
- Shimano Deore XT MT800
-
Size 160 mm
-
Weight 170 g
Wheels
-
Front Wheel
- DT Swiss ARC 1600
-
Axle dimension 12x100 mm
-
Rotor mount Center Lock
-
Rim height 62 mm
-
Inner width 20 mm
-
Rim material Carbon
-
Weight 864 g
-
Rear Wheel
- DT Swiss ARC 1600 Dicut
-
Axle dimension 12x142 mm
-
Rotor mount Center Lock
-
Rim height 62 mm
-
Inner width 20 mm
-
Rim material Carbon
-
Weight 979 g
-
Tyre
- Continental Grand Prix 5000 25mm
-
Width 25 mm
-
Weight 245 g
-
Tyre
- Continental Grand Prix 5000, 28 mm
-
Width 28 mm
-
Weight 245 g
-
Thru Axle
- DT Swiss Through Axle
-
Axle dimension 12x100 mm
-
Thru Axle
- DT Swiss Through Axle
-
Axle dimension 12x142 mm
Cockpit
-
Cockpit
- Canyon H36 Aerocockpit
- A one-piece cockpit with top-end aerodynamics, semi-integrated cable routing, and premium ergonomics for comfort and precise handling.
-
Material Carbon (CF)
-
Weight 365 g
-
Handlebar Tape
- Canyon Ergospeed Gel
- Grippy, durable bar tape with a premium, high-quality, comfortable feel.
-
Color Black
Seat
-
Saddle
- Selle Italia Model X
-
Width 145 mm
-
Gender Unisex
-
Weight 310 g
-
Seatpost
- Canyon SP0079 Aero Seatpost
- Super-stiff, superlight carbon seatpost with unique blade form. Sculpted in the wind tunnel using advanced CFD technology.
-
Material Carbon (CF)
-
Weight 980 g
Light
-
Lights
- Reflector Set
Accessories
-
Pedals
- None included
-
Manuals and Accessories
- Canyon Organza Bag
-
Manuals and Accessories
- Canyon Assembly Paste
-
Manuals and Accessories
- Canyon Note about Cockpit Clamp H31
-
Manuals and Accessories
- Canyon Starter Box
-
Manuals and Accessories
- Canyon Torque Wrench
-
Manuals and Accessories
- Endurace Quick Start Guide
-
Manuals and Accessories
- Quick start guide V07 Aeroad
| Frame size | ||||||||
|
Body Height in cm
|
≤ 160 | 160 - 166 | 166 - 172 | 172 - 178 | 178 - 184 | 184 - 190 | 190 - 196 | ≥ 196 |
|
a
Seat Height in mm
|
581 - 661 | 611 - 691 | 641 - 721 | 671 - 751 | 701 - 801 | 731 - 831 | 761 - 861 | 791 - 891 |
|
b
Seat Tube Length in mm
|
413 | 443 | 473 | 503 | 533 | 563 | 593 | 623 |
|
c
Top Tube Length in mm
|
501 | 520 | 533 | 549 | 559 | 572 | 598 | 613 |
|
d
Head Tube Length in mm
|
103 | 121 | 109 | 126 | 147 | 167 | 193 | 211 |
|
e
Head Tube Angle
|
71° | 71,5° | 71,5° | 72,75° | 73,25° | 73,25° | 73,5° | 73,75° |
|
f
Seat Tube Angle
|
73,5° | 73,5° | 73,5° | 73,5° | 73,5° | 73,5° | 73,5° | 73,5° |
|
g
Chainstay Length in mm
|
405 | 405 | 410 | 410 | 410 | 410 | 410 | 410 |
|
h
Wheel Base in mm
|
951 | 967 | 977 | 984 | 989 | 1.002 | 1.025 | 1.038 |
|
i
Stack in mm
|
483 | 498 | 521 | 539 | 560 | 580 | 606 | 624 |
|
j
Reach in mm
|
358 | 372 | 378 | 390 | 393 | 401 | 419 | 429 |
|
k
Stand-over Height in mm
|
708 | 729 | 759 | 785 | 810 | 834 | 860 | 884 |
|
l
Bottom Bracket Offset in mm
|
57 | 57 | 72 | 70 | 70 | 70 | 70 | 70 |
|
Stack+ in mm
|
574 | 589 | 613 | 630 | 653 | 675 | 700 | 719 |
|
Reach+ in mm
|
415 | 430 | 446 | 459 | 473 | 490 | 509 | 529 |
| Frame size | ||||||||
|
Spacer in mm
|
27,5 | 27,5 | 27,5 | 27,5 | 27,5 | 27,5 | 27,5 | 27,5 |
|
Cockpit Dimensions in mm
|
90-390 | 90-390 | 90-390 | 90-390 | 100-410 | 110-410 | 110-410 | 120-430 |
|
Crank Length in mm
|
165,0 | 165,0 | 170,0 | 172,5 | 172,5 | 175,0 | 175,0 | 175,0 |
|
Chainring Size
|
52/36 | 52/36 | 52/36 | 52/36 | 52/36 | 52/36 | 52/36 | 52/36 |
|
Seat Post Length in mm
|
280 | 280 | 280 | 280 | 300 | 300 | 300 | 300 |
|
Maximum Seat Post Insertion Depth in mm
|
160 | 160 | 160 | 160 | 180 | 180 | 180 | 180 |
|
Minimum Seat Post Insertion Depth in mm
|
80 | 80 | 80 | 80 | 80 | 80 | 80 | 80 |
|
Wheel Size
|
27.5" | 27.5" | 28" | 28" | 28" | 28" | 28" | 28" |
|
Disc Size in mm
|
140 / 140 | 140 / 140 | 160 / 160 | 160 / 160 | 160 / 160 | 160 / 160 | 160 / 160 | 160 / 160 |
|
Rim height in mm
|
50 | 50 | 62 | 62 | 62 | 62 | 62 | 62 |
Aeroad CF SL 8 support
Bike classification
Bikes of this category are designed for riding on hard-surface roads where the wheels remain in permanent contact to the ground. These are in general road racing bicycles with racing handlebars or straight handlebars, triathlon or time trial bicycles. The permissible maximum overall weight comprising rider, luggage and bicycle should not exceed 120 kg. Under certain circumstances this permissible maximum weight can be further limited by the component manufacturers’ recommendations for use. Proven cyclocross and gravel bikes with racing handlebars and cantilever or disc brakes are a special case in this category. In addition, these bikes are also suitable for gravel paths and off-road trails where a short loss of tyre contact with the ground due to small stairs or steps at a height of 15 to 20 cm can occur.
Disclaimer
Subject to technical modification without notice. Errors and omissions excepted.
-
