Exceed CF SL 7.0

Who said that carbon wheels were only for the pros? The Exceed CF SL 7.0 brings together a Reynolds carbon wheelset and other racing-grade components for a bike in a setup that’s ready to win.

Customer reviews (57)

Colour: Two Tone Black

Members only product.

Select frame size

What’s my size?
Find out in 3 steps

Sold out

Members only product.

Sold out

Highlights Exceed CF SL 7.0

Components

Content is loading

Frame

Frame
- Canyon Exceed CF SL
- Material Carbon
- Axle Dimension 12 x 148 mm
- Brake Mount Post Mount 160
Suspension Fork
- RockShox SID Select Remote
- Travel 100 mm
- Weight 1,740 g

Drivetrain

Rear Derailleur
- SRAM GX Eagle
- Cage length long
- Weight 300 g
Shift Lever
- SRAM GX Eagle
- Weight 128 g
Cassette
- SRAM XG-1275 Eagle 10-50 12s
- Number of sprockets 12
- Range 10-50
Crank
- Truvativ Stylo 7K DUB 34T
- Number of chainrings 1
Bottom bracket
- SRAM Pressfit DUB
- Bottom bracket standard PF 89,5
- Weight 79 g
Chain
- SRAM GX Eagle 12s

Brakes

Disc Brake
- SRAM Hinge Clamp
Disc Brake
- SRAM Level TL
Disc Brake
- SRAM Level TL
Brake Rotor
- SRAM Centerline Rounded
- Size 160 mm
- Weight 154 g
Brake Rotor
- SRAM Centerline Rounded
- Size 180 mm
- Weight 193 g

Wheels

Front Wheel
- Reynolds TR 249 C
- Rotor mount Center Lock
- Weight 1,350 g
Rear Wheel
- Reynolds TR 249 C XD
- Rotor mount Center Lock
- Weight 2,560 g
Tyre
- "MAXXIS Rekon 2.25"""
- Width 2.25"
- Weight 720 g
Tyre
- MAXXIS Aspen 2.25"
- Width 2.25"
- Weight 660 g
Thru Axle
- Canyon Quixle

Cockpit

Stem
- Race Face Ride
- Size XS and S bikes are specced with Iridium stems.
- Fork steer tube diameter 1 1/8"
Handlebar
- Race Face Ride Flatbar
- Width 720 mm
Grips
- Ergon GA20

Seat

Saddle
- Selle Italia SLS
- Gender Unisex
- Max. Rider Weight 100 kg
- Weight 10 g
Seatpost
- Race Face Ride
- Seatpost diameter 30,9 mm
- Material Aluminium (AL)
- Weight 295 g
Seat Clamp
- Canyon SC0001

Accessories

Pedals
- None included
Manuals and Accessories
- Canyon Organza Bag
Manuals and Accessories
- Canyon Assembly Paste
Manuals and Accessories
- Canyon Smallbox
Manuals and Accessories
- Canyon Torque Wrench
Manuals and Accessories
- Canyon Shock Pump 300 Psi

Content is loading

Geometry & dimensions

Basic geometry

Detailed geometry table

Body Height in cm	≤ 172	172 - 182	182 - 192	≥ 192
Seat Height in mm (a)	603 - 753	648 - 798	693 - 843	753 - 903
Seat Tube Length in mm (b)	395	440	485	545
Top Tube Length in mm (c)	568	600	620	650
Head Tube Length in mm (d)	87	97	112	142
Head Tube Angle (e)	69,5°	69,5°	69,5°	69,5°
Seat Tube Angle (f)	74°	74°	74°	74°
Chainstay Length in mm (g)	427	427	432	437
Wheel Base in mm (h)	1.078	1.111	1.138	1.175
Stack in mm (i)	604	611	625	653
Reach in mm (j)	395	425	441	463
Stand-over Height in mm (k)	763	791	822	866
Bottom Bracket Offset in mm (l)	65	63	63	63

Component geometry

Detailed geometry table

Spacer in mm	5,0	10,0	15,0	20,0
Stem Length in mm	70	80	90	100
Handlebar Width in mm	720	720	720	720
Crank Length in mm	170,0	175,0	175,0	175,0
Chainring Size	34	34	34	34
Seat Post Diameter in mm	30,9	30,9	30,9	30,9
Seat Post Length in mm	400	400	400	400
Maximum Seat Post Insertion Depth in mm	240	240	240	240
Minimum Seat Post Insertion Depth in mm	90	90	90	90
Wheel Size	29"	29"	29"	29"
Disc Size in mm	180 / 160	180 / 160	180 / 160	180 / 160
Front Fork Travel in mm	100	100	100	100
