Torque 6

Name: Torque 6
Brand: Canyon
Price: 2999.00 EUR
Rating: 5 (9 reviews)

2.999,00 €

(9)

Find your size:

Find your size

For the best results, click on the "Help" texts for detailed explanations on how to carry out each specific measurement.

Your height

Your inseam

Select frame size:

2.999,00 €

Included:

Not included:

Shipping & Packaging

Front Fork Travel

180 mm
Material

Aluminium (AL)
Weight

16.04 kg

Torque 6 Trail, enduro or downhill, you choose. The Torque 6 is a versatile gravity bike that blurs the boundaries and brings big performance to serious downhill riding. It can be used for everything from hitting bike park jumps or all-day big mountain epics.

See components

See geometry & dimensions

Recommended gear

Downtube Cover with Cable Channel

The downtube cover integrates seamlessly into the frame and doesn’t just protect your bike from dings and scratches, it also functions as a rattle-silencing cable channel and makes replacing cables a simple and easy process.

Geometry

Super enduro, park bike, freeride, call it whatever you like. What matters is that the geometry of the Torque offers superior control and stability at speed, while remaining agile and playful on track and in the air.

Average customer rating

4,9 out of 5

9 customers reviewed

The highlights of this component set

Ready to shred: this bike’s Fox suspension and Shimano shifting and brakes give you everything you need for demanding descents and clocking up big airtime.

View all components

Suspension Fork

FOX 38 Performance Grip

With 180 mm of travel and thick 38 mm thick stanchions, the new Fox 38 provides maximum stiffness under steering and braking for top traction and control. The GRIP damper provides consistent damping performance with increased durability. Featuring stepless compression adjustment.
Rear Shock

FOX DPX2 Performance

The DPX2 air shock works optimally with the Torque’s Canyon-developed Triple Phase Kinematics. It provides excellent sensitivity even on long descents. And thanks to increased compression damping levels, the rear triangle is more stable for increased climbing performance.
Disc Brake

Shimano SLX M7120

When you’re bombing the big descents, you need brakes you can fully rely on. And with big 203 mm rotors front and rear, Shimano SLX provide stopping power when you need it most – even on the longest downhill sections. Featuring tool-free reach adjustment.
Rear Derailleur

Shimano SLX, 12-speed

Shimano’s accurate and reliable 12-speed SLX shifting combines a 32-tooth chainring with a 10-51 cassette for a huge 510% gear range that keeps you pedalling on technical descents and steep climbs alike.

View all components

Geometry Table

Understanding your bike's geometry is the key to a great fit and comfortable ride.

Basic geometry

Detailed geometry table
	S Your selected size	M Your selected size	L Your selected size	XL Your selected size
Body Height in cm	< 170	170 - 178	178 - 186	> 186
Seat Height in mm (a)	653 - 783	693 - 823	728 - 848	773 - 893
Seat Tube Length in mm (b)	400	440	455	500
Top Tube Length in mm (c)	597	620	642	665
Head Tube Length in mm (d)	115	128	135	145
Head Tube Angle (e)	65°	65°	65°	65°
Seat Tube Angle (f)	74°	74°	74°	74°
Chainstay Length in mm (g)	425	428	428	428
Wheel Base in mm (h)	1.171	1.195	1.219	1.243
Stack in mm (i)	618	627	636	645
Reach in mm (j)	420	440	460	480
Stand-over Height in mm (k)	759	761	762	776
Bottom Bracket Offset in mm (l)	15	15	15	15

Component geometry

Detailed geometry table
	S Your selected size	M Your selected size	L Your selected size	XL Your selected size
Spacer in mm	15,0	15,0	15,0	15,0
Stem Length in mm	40	40	40	40
Handlebar Width in mm	780	780	800	800
Crank Length in mm	165,0	165,0	165,0	165,0
Chainring Size	32	32	32	32
Seat Post Diameter in mm	30,9	30,9	30,9	30,9
Dropper post travel in mm	150	150	170	170
Seat Post Length in mm	425	425	465	465
Maximum Seat Post Insertion Depth in mm	220	220	240	240
Seat Post Insertion Depth in mm	90	90	120	120
Wheel Size	27,5"	27,5"	27,5"	27,5"
Disc Size in mm	180 / 203	180 / 203	180 / 203	180 / 203
Front Fork Travel in mm	180	180	180	180
Rear Suspension Travel in mm	175	175	175	175

All components
Frame
Frame

Canyon Torque

Rear Shock

FOX DPX2 Performance

Suspension Fork

FOX 38 Performance Grip
Drivetrain
Rear Derailleur

Shimano SLX, 12-speed

12-speed, max cassette size: 51T. Weight: 310 g, Shadow RD+ chain stabilizing system

Chainguard

e*thirteen TRS ISCG05

Shift Lever

Shimano SLX, 12-speed

Rear derailleur shifter, 12-speed, 2-way release, I-Spec EV clamp allows 14mm lateral adjustment and 20-degrees rotation adjustment, 133 g

Cassette

Shimano SLX, 12-speed (10-51)

Primarily-steel cogs with aluminium 51T cog, Microspline interface, Gear range: 10-51T, weight: 533 g, Hyperglide+ technology provides better chain engagement.

Crank

Shimano SLX M7100 32T

Bottom bracket

Shimano MT800, Threaded

Hassle-free Shimano Hollowtech II threaded bottom bracket

Chain

Shimano CN-M7100 12s
Brakes
Disc Brake

Shimano SLX M7120

Disc Brake

Shimano SLX M7120

Brake Rotor

Shimano RT70

Disc Mount: Centerlock

Brake Rotor

Shimano SLX rotor, 203mm
Wheels
Wheel

RaceFace AR30

Wheel

RaceFace AR30 | Shimano MT510 SH12

Tyre

MAXXIS Minion DHR II 2.4''

Casing: Exo

Compound: 3C Maxx Grip

Technology: Tubeless ready

Tyre

MAXXIS Minion DHR II 2.4''

Thru Axle

Canyon Thru Axle, Boost 148

The Boost 148-compatible, Canyon rear through-axle increases stiffness, and is both simple and reliable.
Cockpit
Stem

Canyon G5 Stem 40mm

The Canyon G5 stem (40mm extension) is both incredibly strong and beautifully designed.

Handlebar

Canyon G5 Riserbar

Our aluminum G5 Riser bar offers the perfect combination of width (780mm) and rise (30mm).

Grips

Canyon G5 Lock-On

Canyon's G5 Lock-On grips are comfortable and secure.
Seat
Saddle

Ergon SM10 Enduro Comp

Developed on the Enduro World Series, the SM10 gives you max freedom of movement in technical terrain.

Seatpost

Iridium Dropper Post

Iridium dropper posts provide seat-height adjustability, varying depending on frame size. Internally routed, cable actuated, 30.9mm diameter
Accessories
Pedals

None included

Manuals and Accessories

Canyon tool case

Manuals and Accessories

CANYON Instruction Manual Rear Derailleur

Manuals and Accessories

Canyon Smallbox

Content: Manual, Torque Wrench incl. Bit Set, Shock Pump, Assembly Paste
Spare & Wear Parts
Derailleur hanger

Shop Derailleur Hanger GP0155-01

These bikes can be used by technically adept and experienced riders to tackle very challenging, extremely steep terrain with a high number of obstacles. In this category, big jumps are to be expected as well as intensive use in bike parks or on downhill courses. It is essential that these bikes are fully examined for any potential damage after every ride. Further use when using damaged parts could lead to a major component malfunction. In addition, safety-relevant parts should be replaced at regular intervals. Wearing appropriate protective gear is absolutely essential. This category includes long-travel full-suspension bikes as well as dirt bikes.

We’re in Control

Our business model gives us the advantage of knowing exactly where our products come from, how they are made and what they are capable of. Canyon products are exclusively available at Canyon.com, so you can trust the quality you are getting.

Disclaimer

Subject to technical modification without notice. Errors and omissions excepted.
