Lux World Cup CF 6
18,099 US$
Original price
You save 7,900 US$
This rapid XC race bike makes our World Cup-level performance DNA available in a more accessible package. With its top-end carbon frame, aggressive geometry, and reliable components, the Lux World Cup 6 is made to win.
- Front Fork Travel: 100 mm
-
Weight:
12.1 kg
WeightWeight is based on a size medium frame.
-
-
Members only product. Log in here
Select frame size
Delivery:
Select frame size
Members only product.
Log in here
Additional information
Current delivery times information.
Read more
Not included:
-
Your bike already arrives 95% built. We give you the tools. And simple instructions. No technical skills needed.
-
That’s our quality promise – if you’re not 100% happy with your bike, we’re not happy either.
Learn more
Delivery:
Select frame size
Highlights Lux World Cup CF 6

It climbs and climbs and climbs
Find yourself beating your best times with a bike that won’t quit climbing. The advanced kinematics, efficient shock position and rocker link, and anti-squat values have seen it conquer the toughest courses, dominate Marathon races, and smash PBs on local trails.

It rips descents too
There’s no point in leading the pack on the clubs if they’re going to overtake you on the way down. The Lux World Cup’s slack 68.5-degree head angle chews up steep downhill sections with the long reach and short stem putting you in control and any speed.

Clean, sleek cables designed for racing
Fully integrated cables isn’t just an aesthetic choice but also designed to give your peace of mind when you’re sole focus is the next lap. Unlike semi integrated cables, usually routed over the bottom bracket, there’s no risk of debris build up or track snags ruining your race. In the long term, there’s no risk of smaller particles harming the integrity of your frame keeping your race ready for longer.

Shaving grams, boosting performance
We’ve eliminated every last unnecessary gram so that you have the most efficient experience possible. Creating a carbon flex pivot, developing a lighter rear triangle, and upgrading the bearings means only the essential remains.

Ready for anything remote lockout
Adjust your ride on the fly with our handle bar controlled remote lockout. Whether you’re tackling a spicy downhill section or sprinting for the finish line, the 2 position suspension lockout, easily accessible from the bar gives you in-race adjustments and the competitive edge.

Stay hydrated
All Lux World Cup CF models have space for mounting two large bottles – even on the smallest bikes in size XS. So you can keep pushing the pace lap after lap.

Integrated cable routing
Routing brake and shifting cables and lines from the handlebar through the frame creates a super-clean look and keeps your bike running smoother by protecting everything from the elements. And on the Lux, we’ve taken one step further – by routing them directly through the headset. They leave the frame through the rear triangle, not under the bottom bracket like on a typical design, meaning the bike collects less dirt and stays lighter in muddy conditions. All little details that add up to take seconds off your time.

Impact Protection Unit 2.0
Our latest IPU – short for Impact Protection Unit – is perfectly integrated into the frame at the headset and protects the top tube from over-rotating handlebars in the event of a crash. The system doesn’t affect the bike’s manoeuvrability – you can still turn the bars far enough to nail the tightest switchbacks on the course.
Content is loading
Frame
-
Frame
- Canyon Lux WC CF
- Lightweight full-suspension carbon XC frame, featuring the World Championship-winning design DNA of the flagship Lux World Cup CFR.
- Axle dimension: 12x148 mm
- Material: Carbon (CF)
- Weight: 1,123 g
-
Rear Shock
- FOX Float DPS Performance Elite Remote
- Weight: 980 g
-
Suspension Fork
- FOX 32 Step-Cast Performance Remote
- Axle dimension: 15x110 mm
- Stanchion Diameter: 32 mm
- Travel: 100 mm
- Fork steer tube diameter: 1 1/8" - 1,5"
- Weight: 10 g
Drivetrain
-
Rear Derailleur
- Shimano Deore SLX M7100
- Cage length: long
- Weight: 310 g
-
Shift Lever
- Shimano Deore SLX M7100
- Weight: 143 g
-
Cassette
- Shimano Deore SLX CS-M7100
- Number of sprockets: 12
- Range: 10-51
-
Crank
- Shimano SLX M7120
- Number of chainrings: 1
-
Bottom bracket
- Shimano Pressfit BB71
- Bottom bracket standard: PF 89,5/92
- Weight: 71 g
-
Chain
- Shimano CN-M7100 12s
Brakes
-
Disc Brake
- Shimano SLX BR-M7110
- Number of pistons: 2
-
Disc Brake
- Shimano SLX M7110
- Number of pistons: 2
-
Brake Rotor
- Shimano RT66 160
- Size: 160 mm
- Weight: 110 g
-
Brake Rotor
- Shimano RT66 180
- Size: 180 mm
- Weight: 140 g
Wheels
-
Front Wheel
- DT Swiss X 1900 Spline
- Axle dimension: 15x110 mm
- Rotor mount: IS 6-bolt
- Inner width: 25 mm
- Rim material: Aluminium
- Weight: 881 g
-
Rear Wheel
- DT Swiss X 1900 Spline
- Axle dimension: 12x148 mm
- Rotor mount: IS 6-bolt
- Inner width: 30 mm
- Rim material: Aluminium
- Weight: 1,001 g
-
Tyre
- Maxxis Ikon EXO MaxxSpeed
- Width: 2.35"
- Weight: 835 g
-
Thru Axle
- Canyon Quixle Through Axle QR 148x12
- Axle dimension: 12x148 mm
Cockpit
-
Stem
- Race Face Ride
- Fork steer tube diameter: 1 1/8" - 1 1/4"
-
Handlebar
- Race Face Ride Rise
- Clamping diameter: 31,8 mm
- Width: 740 mm
-
Grips
- Ergon GA20
Seat
-
Saddle
- Ergon SR10 Pro Sport
- Gender: Male
- Weight: 250 g
-
Seatpost
- Race Face Ride
- Seatpost diameter: 30,9 mm
- Material: Aluminium (AL)
- Weight: 295 g
-
Seat Clamp
- Canyon SC0001
Accessories
-
Pedals
- None included
-
Manuals and Accessories
- Canyon Organza Bag
-
Manuals and Accessories
- Canyon Assembly Paste
-
Manuals and Accessories
- Canyon Torque Wrench
-
Manuals and Accessories
- Quick Start Guide
-
Manuals and Accessories
- Canyon Shock Pump 300 Psi
-
Manuals and Accessories
- CAYN SMALL BOX 2.0
Content is loading
Content is loading
Body Height in cm
|
≤ 166 | 166 - 175 | 175 - 183 | 183 - 192 | ≥ 192 |
---|---|---|---|---|---|
Seat Height in mm
(a)
|
583 - 733 | 623 - 773 | 663 - 813 | 703 - 853 | 743 - 893 |
Seat Tube Length in mm
(b)
|
375 | 415 | 455 | 495 | 535 |
Top Tube Length in mm
(c)
|
565 | 585 | 606 | 630 | 653 |
Head Tube Length in mm
(d)
|
90 | 90 | 95 | 110 | 125 |
Head Tube Angle
(e)
|
68,5° | 68,5° | 68,5° | 68,5° | 68,5° |
Seat Tube Angle
(f)
|
75° | 75° | 75° | 75° | 75° |
Chainstay Length in mm
(g)
|
430 | 430 | 430 | 430 | 430 |
Wheel Base in mm
(h)
|
1.100 | 1.120 | 1.142 | 1.167 | 1.193 |
Stack in mm
(i)
|
577 | 577 | 582 | 596 | 610 |
Reach in mm
(j)
|
410 | 430 | 450 | 470 | 490 |
Stand-over Height in mm
(k)
|
777 | 777 | 780 | 784 | 793 |
Bottom Bracket Offset in mm
(l)
|
38 | 38 | 38 | 38 | 38 |
Spacer in mm
|
15,0 | 15,0 | 15,0 | 15,0 | 15,0 |
---|---|---|---|---|---|
Stem Length in mm
|
70 | 70 | 70 | 70 | 70 |
Handlebar Width in mm
|
740 | 740 | 740 | 740 | 740 |
Crank Length in mm
|
170,0 | 170,0 | 175,0 | 175,0 | 175,0 |
Chainring Size
|
34 | 34 | 34 | 34 | 34 |
Seat Post Diameter in mm
|
30,9 | 30,9 | 30,9 | 30,9 | 30,9 |
Seat Post Length in mm
|
400 | 400 | 400 | 400 | 400 |
Maximum Seat Post Insertion Depth in mm
|
240 | 240 | 240 | 240 | 240 |
Minimum Seat Post Insertion Depth in mm
|
90 | 90 | 90 | 90 | 90 |
Wheel Size
|
29" | 29" | 29" | 29" | 29" |
Disc Size in mm
|
180 / 160 | 180 / 160 | 180 / 160 | 180 / 160 | 180 / 160 |
Front Fork Travel in mm
|
100 | 100 | 100 | 100 | 100 |
Rear Suspension Travel in mm
|
100 | 100 | 100 | 100 | 100 |
Fitting Length
|
210X50 | 210X50 | 210X50 | 210X50 | 210X50 |
Download PDF
Content is loading
Lux World Cup CF 6 support
Bike classification
This category also covers the requirements of categories 1-2. In addition it includes use on harsher, unpaved terrain. The scope for these bikes includes occasional jumps up to a maximum height of 60 cm. Jumps of this scale can cause inexperienced riders to have accidents on landing, which can result in injury. Hardtail mountain bikes and full-suspension bikes with short travel are included in this category.
Disclaimer
Subject to technical modification without notice. Errors and omissions excepted.
