Inflite CF SLX 8 AXS
-
Weight:
7.56 kg
WeightWeight is based on a size medium frame.
- Material: Carbon (CF)
-
-
Members only product. Log in here
-
Financing with CetelemCetelem offers flexible monthly payments with a fixed interest rateCalculate amountFinancing with SplititNo credit checks, 0% interest. Pay monthly for your order with your existing credit card.Calculate amount
-
Stress free New Bike DayOur most premium service. Collect your new bike directly from Canyon, fully assembled and set up by a Canyon mechanic. They will answer any questions and ensure you're ready to ride.
How to choose New Bike DayCollect & RideNervous about building your new bike? Have your bike sent directly to your local bike shop to be assembled by an expert. Collect your bike at a time that suits you.
How to choose Collect & Ride -
Your bike already arrives 95% built. We give you the tools. And simple instructions. No technical skills needed.
-
That’s our quality promise – if you’re not 100% happy with your bike, we’re not happy either.
Learn more
Highlights Inflite CF SLX 8 AXS

Benchmark comfort: in the saddle, and on your shoulder

Less mud, more speed

High-end carbon fibre layup

Integrated seatpost clamp
Frame
-
Frame
- Canyon Inflite CF SLX Disc
- Superlight build of the latest-generation Inflite cyclocross race bike. With World Championship-winning geometry, mud-shedding tube forms, and shoulder-friendly seat tube kink.
- Axle dimension: 12x142 mm
- Tyre clearance: 35 mm
- Material: Carbon (CF)
- Weight: 1,258 g
-
Fork
- Canyon FK0045 CF Disc
- Axle dimension: 12x100 mm
- Fork steer tube diameter: 1 1/4"
- Tyre clearance: 35 mm
- Material: Carbon (CF)
- Weight: 980 g
Drivetrain
-
Battery
- SRAM Powerpack
-
Rear Derailleur
- SRAM Force AXS RD 12s
- Weight: 306 g
-
Chainguard
- Canyon EP0703-02 Chainguide with screws
-
Cassette
- SRAM Force XG-1270, 12speed, 10-36
- Number of sprockets: 12
-
Crank
- SRAM Force AXS Powermeter
- Number of chainrings: 1
-
Bottom bracket
- SRAM DUB Pressfit
- Bottom bracket standard: PF 86,5
- Weight: 67 g
-
Chain
- SRAM Force D1 12-Speed
- With signature flat-top design for quieter operation and increased strength and durability.
Brakes
-
Shift-/ Brake Lever
- SRAM Force AXS HRD, 12-speed
- Number of pistons: 2
- Weight: 401 g
-
Shift-/ Brake Lever
- SRAM Force AXS HRD D2
- Number of pistons: 2
- Weight: 405 g
-
Brake Rotor
- SRAM Centerline X Rounded Edges
- Size: 140 mm
- Weight: 103 g
-
Brake Rotor
- SRAM Centerline, 160mm
- Size: 160 mm
- Weight: 117 g
Wheels
-
Front Wheel
- DT Swiss CRC 1400 Spline
- Axle dimension: 12x100 mm
- Rotor mount: Center Lock
- Rim height: 45 mm
- Weight: 671 g
-
Rear Wheel
- DT Swiss CRC 1400 Spline XDR
- Axle dimension: 12x142 mm
- Rotor mount: Center Lock
- Rim height: 45 mm
- Weight: 854 g
-
Tyre
- Schwalbe X-One R Evo
- Width: 33 mm
- Weight: 418 g
-
Thru Axle
- Canyon Through Axle
- Axle dimension: 12x100 mm
- Material: Aluminium (AL)
-
Thru Axle
- Canyon Thru Axle
- Axle dimension: 12x142 mm
Cockpit
-
Cockpit
- Canyon H31 Ergocockpit CF
- Carbon one-piece stem-handlebar unit with shorter reach and the 3° flare angle for increased control when riding in the drops.
- Material: Carbon
- Shape: Ergo
- Reach: 70 mm
- Drop: 128 mm
-
Handlebar Tape
- Canyon Ergospeed Gel
- Grippy, durable bar tape with a premium, high-quality, comfortable feel.
- Color: black
Seat
-
Saddle
- Selle Italia SLR Boost
- Gender: Unisex
- Max. Rider Weight: 100 kg
- Weight: 195 g
-
Seatpost
- Canyon S14 VCLS 2.0 CF
- Material: Carbon
- Setback: -2 mm / 10 mm
- Technology: VCLS 2.0 | Fliphead
- Weight: 220 g
Accessories
-
Pedals
- None included
-
Manuals and Accessories
- Canyon Organza Bag
-
Manuals and Accessories
- Canyon Assembly Paste
-
Manuals and Accessories
- Canyon Note about Cockpit Clamp H31
-
Manuals and Accessories
- Canyon Torque Wrench
-
Manuals and Accessories
- Endurace Quick Start Guide
-
Manuals and Accessories
- Canyon starter box
Body Height in cm
|
≤ 160 | 160 - 166 | 166 - 172 | 172 - 178 | 178 - 184 | 184 - 190 | 190 - 196 | ≥ 196 |
---|---|---|---|---|---|---|---|---|
Seat Height in mm
(a)
|
613 - 713 | 643 - 743 | 673 - 773 | 703 - 803 | 733 - 833 | 763 - 863 | 793 - 893 | 823 - 923 |
Seat Tube Length in mm
(b)
|
422 | 452 | 482 | 512 | 542 | 572 | 602 | 632 |
Top Tube Length in mm
(c)
|
501 | 522 | 532 | 550 | 562 | 578 | 601 | 617 |
Head Tube Length in mm
(d)
|
94 | 113 | 102 | 119 | 146 | 168 | 192 | 214 |
Head Tube Angle
(e)
|
70,2° | 71,5° | 71° | 72,25° | 72,5° | 72,5° | 72,7° | 72,7° |
Seat Tube Angle
(f)
|
73,5° | 73,5° | 73,5° | 73,5° | 73,5° | 73,5° | 73,5° | 73,5° |
Chainstay Length in mm
(g)
|
415 | 415 | 425 | 425 | 425 | 425 | 425 | 425 |
Wheel Base in mm
(h)
|
970 | 980 | 1.000 | 1.006 | 1.018 | 1.034 | 1.055 | 1.072 |
Stack in mm
(i)
|
487 | 510 | 527 | 547 | 572 | 593 | 616 | 637 |
Reach in mm
(j)
|
357 | 371 | 376 | 388 | 393 | 402 | 418 | 428 |
Stand-over Height in mm
(k)
|
725 | 749 | 783 | 807 | 839 | 859 | 883 | 909 |
Bottom Bracket Offset in mm
(l)
|
55 | 55 | 66 | 66 | 64 | 64 | 64 | 64 |
Stack+ in mm
|
576 | 598 | 618 | 637 | 663 | 686 | 709 | 732 |
Reach+ in mm
|
403 | 419 | 433 | 446 | 462 | 481 | 497 | 517 |
Spacer in mm
|
27,5 | 27,5 | 27,5 | 27,5 | 27,5 | 27,5 | 27,5 | 27,5 |
---|---|---|---|---|---|---|---|---|
Cockpit Dimensions in mm
|
70-380 | 70-400 | 80-420 | 80-420 | 90-420 | 100-440 | 100-440 | 110-460 |
Crank Length in mm
|
165,0 | 165,0 | 170,0 | 170,0 | 172,5 | 175,0 | 175,0 | 175,0 |
Chainring Size
|
40 | 40 | 40 | 40 | 40 | 40 | 40 | 40 |
Seat Post Diameter in mm
|
27,2 | 27,2 | 27,2 | 27,2 | 27,2 | 27,2 | 27,2 | 27,2 |
Seat Post Length in mm
|
350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 |
Maximum Seat Post Insertion Depth in mm
|
207 | 207 | 207 | 207 | 207 | 207 | 207 | 207 |
Minimum Seat Post Insertion Depth in mm
|
107 | 107 | 107 | 107 | 107 | 107 | 107 | 107 |
Wheel Size
|
27.5" | 27.5" | 28" | 28" | 28" | 28" | 28" | 28" |
Disc Size in mm
|
140 / 140 | 140 / 140 | 140 / 140 | 160 / 140 | 160 / 140 | 160 / 140 | 160 / 160 | 160 / 160 |
Inflite CF SLX 8 AXS support
Bike classification
Bikes of this category are designed for riding on hard-surface roads where the wheels remain in permanent contact to the ground. These are in general road racing bicycles with racing handlebars or straight handlebars, triathlon or time trial bicycles. The permissible maximum overall weight comprising rider, luggage and bicycle should not exceed 120 kg. Under certain circumstances this permissible maximum weight can be further limited by the component manufacturers’ recommendations for use. Proven cyclocross and gravel bikes with racing handlebars and cantilever or disc brakes are a special case in this category. In addition, these bikes are also suitable for gravel paths and off-road trails where a short loss of tyre contact with the ground due to small stairs or steps at a height of 15 to 20 cm can occur.
Disclaimer
Subject to technical modification without notice. Errors and omissions excepted.
