Lux CF SLX 9 LTD
-
Out of stock
6,149 US$
Original price
You save 700 US$
With a sub-2 kg frame weight and the best components available on the market today, the Lux CF SLX 9 LTD is one of the lightest XC race bikes in the world. Premium, limited-edition, highly efficient – an all-out carbon race-winner.
Members only product.
Log in here
Additional information
Current delivery times information.
Read more
Not included:
Delivery:
Select frame size
Highlights Lux CF SLX 9 LTD

Instant Speed
The Lux is one of the fastest, most efficient machines to be found. The only way to make it faster? Add a handlebar-mounted, suspension lockout. And that’s precisely what we did on all our SLX models.

No Dropped Chains
A dropped chain can mean a lost race, which is why we equip Lux CF SLX models with the lightest chain guide available. Our minimalist guide helps keep your chain in place no matter how rough the course.

Rear Suspension Made Light
We’ve equipped the Lux with a lightweight flex pivot that cuts weight by eliminating conventional bearing hardware. You get smooth suspension and no unnecessary weight.
Content is loading
Frame
-
Frame
- Canyon Lux CF SLX
- A true podium threat, the Lux CF SLX has been our go-to full suspension XC bike for Canyon Factory racers including Mathieu van der Poel and Emily Batty.
- Material: Carbon (CF)
- Weight: 2,300 g
-
Rear Shock
- RockShox SIDLuxe Ultimate Remote
- Positions: 2
- Weight: 290 g
-
Suspension Fork
- RockShox SID SL Ultimate RaceDay Remote
- Axle dimension: 15x110 mm
- Stanchion Diameter: 32 mm
- Travel: 100 mm
- Fork steer tube diameter: 1 1/8" - 1 1/4"
- Weight: 1,600 g
Drivetrain
-
Battery
- SRAM Powerpack
-
Rear Derailleur
- SRAM XX1 Eagle AXS
- Cage length: long
- Weight: 264 g
-
Shift Lever
- SRAM Eagle AXS Controller
- Weight: 70 g
-
Cassette
- SRAM XG-1295
- Number of sprockets: 12
- Range: 10-52 12S
-
Crank
- SRAM XX1 Eagle DUB 34T
- Number of chainrings: 1
-
Bottom bracket
- SRAM Pressfit DUB
- Bottom bracket standard: PF 92
- Weight: 79 g
-
Chain
- SRAM X01 Eagle 12-speed
Brakes
-
Disc Brake
- SRAM Level Ultimate
-
Disc Brake
- SRAM Level Ultimate
-
Brake Rotor
- SRAM Centerline, 160mm
- Size: 160 mm
- Weight: 117 g
-
Brake Rotor
- SRAM Centerline X Rounded Edges
- Size: 180 mm
- Weight: 147 g
Wheels
-
Front Wheel
- Reynolds Blacklabel XC
- Rotor mount: Center Lock
- Weight: 10 g
-
Rear Wheel
- Reynolds Blacklabel XC
- Rotor mount: Center Lock
- Weight: 2,560 g
-
Tyre
- MAXXIS Aspen 2.25"
- Width: 2.25"
- Weight: 660 g
-
Tyre
- Maxxis Ikon Exo 2.35"
- Width: 2.35"
- Weight: 740 g
-
Thru Axle
- Canyon GP0415-04 Thru Axle 148X12
- Axle dimension: 12x148 mm
Cockpit
-
Cockpit
- Canyon CP0008 Cockpit
- Light, stiff one-piece carbon cockpit designed with Canyon’s pro riders for XC riding. Special shape allows ergonomic, comfortable grip near stem and aerodynamic position on straight, flat sections.
- Material: Carbon (CF)
- Weight: 325 g
-
Grips
- Ergon GA20
Seat
-
Saddle
- Selle Italia SLR KC Boost
- Gender: Unisex
- Max. Rider Weight: 100 kg
- Weight: 136 g
-
Seatpost
- DT Swiss D 232 One
- Seatpost diameter: 30,9 mm
- Material: Aluminium (AL)
- Weight: 10 g
-
Seat Clamp
- Canyon SC0001
Accessories
-
Pedals
- None included
-
Manuals and Accessories
- Canyon Organza Bag
-
Manuals and Accessories
- Canyon Assembly Paste
-
Manuals and Accessories
- Canyon Smallbox
-
Manuals and Accessories
- Canyon Torque Wrench
-
Manuals and Accessories
- Canyon Shock Pump 300 Psi
Content is loading
Content is loading
Body Height in cm
|
≤ 175 | 175 - 183 | 183 - 192 | ≥ 192 |
---|---|---|---|---|
Seat Height in mm
(a)
|
683 - 783 | 723 - 823 | 763 - 863 | 803 - 903 |
Seat Tube Length in mm
(b)
|
425 | 465 | 505 | 545 |
Top Tube Length in mm
(c)
|
576 | 599 | 623 | 649 |
Head Tube Length in mm
(d)
|
90 | 100 | 115 | 140 |
Head Tube Angle
(e)
|
70° | 70° | 70° | 70° |
Seat Tube Angle
(f)
|
74,5° | 74,5° | 74,5° | 74,5° |
Chainstay Length in mm
(g)
|
435 | 435 | 435 | 435 |
Wheel Base in mm
(h)
|
1.102 | 1.126 | 1.151 | 1.179 |
Stack in mm
(i)
|
582 | 591 | 605 | 629 |
Reach in mm
(j)
|
415 | 435 | 455 | 475 |
Stand-over Height in mm
(k)
|
786 | 789 | 796 | 811 |
Bottom Bracket Offset in mm
(l)
|
38 | 38 | 38 | 38 |
Spacer in mm
|
5,0 | 10,0 | 15,0 | 20,0 |
---|---|---|---|---|
Cockpit Dimensions in mm
|
80-740 | 80-740 | 80-740 | 80-740 |
Crank Length in mm
|
170,0 | 175,0 | 175,0 | 175,0 |
Chainring Size
|
34 | 34 | 34 | 34 |
Seat Post Diameter in mm
|
30,9 | 30,9 | 30,9 | 30,9 |
Dropper post travel in mm
|
60 | 60 | 60 | 60 |
Seat Post Length in mm
|
400 | 400 | 400 | 400 |
Maximum Seat Post Insertion Depth in mm
|
190 | 190 | 190 | 190 |
Minimum Seat Post Insertion Depth in mm
|
90 | 90 | 90 | 90 |
Wheel Size
|
29" | 29" | 29" | 29" |
Disc Size in mm
|
180 / 160 | 180 / 160 | 180 / 160 | 180 / 160 |
Front Fork Travel in mm
|
100 | 100 | 100 | 100 |
Rear Suspension Travel in mm
|
100 | 100 | 100 | 100 |
Fitting Length
|
210X50 | 210X50 | 210X50 | 210X50 |
Download PDF
Content is loading
Lux CF SLX 9 LTD support
Bike classification
This category also covers the requirements of categories 1-2. In addition it includes use on harsher, unpaved terrain. The scope for these bikes includes occasional jumps up to a maximum height of 60 cm. Jumps of this scale can cause inexperienced riders to have accidents on landing, which can result in injury. Hardtail mountain bikes and full-suspension bikes with short travel are included in this category.
Disclaimer
Subject to technical modification without notice. Errors and omissions excepted.
