Ultimate CF SL 8 Disc RCC
-
Out of stock
4,999 US$
Original price
You save 100 US$
This special-edition Ultimate celebrates the long-standing partnership between Rapha and Canyon. It’s exclusively available to members of the Rapha Cycling Club, a global community of passionate cyclists. Only 250 units are available worldwide, and artwork created in collaboration with Rapha designer Patrick Mafham prominently features RCC’s famous club colours – grey, pink and black.
- Material: Carbon (CF)
-
Weight:
7.46 kg
WeightWeight is based on a size medium frame.
Members only product.
Log in here
Additional 10% off with code "OUTLET10"
Additional information
Current delivery times information.
Read more
Not included:
Delivery:
Select frame size
Highlights Ultimate CF SL 8 Disc RCC
Content is loading
Frame
-
Frame
- Canyon Ultimate CF SL Disc
- Tyre clearance: 31 mm
- Material: Carbon (CF)
- Weight: 927 g
-
Fork
- Canyon FK0051 CF Disc
- Axle dimension: 12x100 mm
- Fork steer tube diameter: 1 1/4"
- Tyre clearance: 31 mm
- Material: Carbon (CF)
- Weight: 395 g
Drivetrain
-
Battery
- SRAM Powerpack
-
Rear Derailleur
- SRAM Force eTap AXS
- Weight: 301 g
-
Front Derailleur
- SRAM Force eTap AXS
- Weight: 162 g
-
Cassette
- SRAM Force XG-1270, 12-speed, 10-28T
- Number of sprockets: 12
-
Crank
- SRAM Force AXS Powermeter
- Number of chainrings: 2
-
Bottom bracket
- SRAM DUB Pressfit
- Bottom bracket standard: PF 86,5
- Weight: 67 g
-
Chain
- SRAM FORCE D1 12-speed
- With signature flat-top design for quieter operation and increased strength and durability. And hard chrome plated inner link plates and rollers for reduced wear.
Brakes
-
Shift-/ Brake Lever
- SRAM Force eTap AXS HRD 2s
- Weight: 605 g
-
Shift-/ Brake Lever
- SRAM Force eTap AXS HRD 12s
- Weight: 610 g
-
Brake Rotor
- SRAM Paceline
- Size: 160 mm
- Weight: 159 g
Wheels
-
Front Wheel
- DT Swiss ARC 1400 Dicut db
- Axle dimension: 12x100 mm
- Rotor mount: Center Lock
- Rim height: 50 mm
- Inner width: 20 mm
- Rim material: Carbon
- Weight: 716 g
-
Rear Wheel
- DT Swiss ARC 1400 Dicut db XDR
- Rotor mount: Center Lock
- Rim height: 50 mm
- Weight: 827 g
-
Tyre
- Continental Grand Prix 5000 25mm
- Width: 25 mm
- Weight: 245 g
-
Thru Axle
- Canyon GP0197-01
- Axle dimension: 12x100 mm
-
Thru Axle
- Canyon GP0235-01
- Axle dimension: 12x142 mm
Cockpit
-
Cockpit
- Canyon CP0030 Aerocockpit
- One-piece carbon cockpit integrating bar and stem into a single sleek unit.
- Material: carbon
- Shape: Ergo
- Reach: 74 mm
- Drop: 130 mm
-
Handlebar Tape
- Canyon Ergospeed Gel
- Grippy, durable bar tape with a premium, high-quality, comfortable feel.
- Color: black
Seat
-
Saddle
- Selle Italia SLR Boost Superflow S saddle
- Width: 130 mm
- Gender: Unisex
- Max. Rider Weight: 100 kg
- Weight: 181 g
-
Seatpost
- Canyon S13 VCLS CF
- Material: Carbon
- Setback: 15 - 35 mm
- Technology: VCLS
- Weight: 220 g
Accessories
-
Pedals
- None included
-
Manuals and Accessories
- Canyon Organza Bag
Content is loading
Content is loading
Body Height in cm
|
≤ 166 | 166 - 172 | 172 - 178 | 178 - 184 | 184 - 190 | 190 - 196 | ≥ 196 |
---|---|---|---|---|---|---|---|
Seat Height in mm
(a)
|
620 - 720 | 653 - 753 | 680 - 780 | 708 - 808 | 740 - 840 | 770 - 870 | 800 - 900 |
Seat Tube Length in mm
(b)
|
434 | 467 | 494 | 522 | 554 | 584 | 614 |
Top Tube Length in mm
(c)
|
513 | 529 | 543 | 556 | 571 | 596 | 612 |
Head Tube Length in mm
(d)
|
89 | 107 | 130 | 148 | 174 | 195 | 213 |
Head Tube Angle
(e)
|
69,6° | 71° | 72,3° | 73,3° | 73,3° | 73,5° | 73,8° |
Seat Tube Angle
(f)
|
73,9° | 73,8° | 73,8° | 73,8° | 73,8° | 73,8° | 73,8° |
Chainstay Length in mm
(g)
|
415 | 415 | 415 | 415 | 415 | 415 | 415 |
Wheel Base in mm
(h)
|
983 | 988 | 993 | 996 | 1.011 | 1.034 | 1.046 |
Stack in mm
(i)
|
500 | 522 | 546 | 567 | 592 | 613 | 631 |
Reach in mm
(j)
|
368 | 378 | 385 | 391 | 399 | 418 | 428 |
Stand-over Height in mm
(k)
|
720 | 748 | 775 | 801 | 828 | 851 | 874 |
Bottom Bracket Offset in mm
(l)
|
72 | 72 | 70 | 70 | 70 | 70 | 70 |
Stack+ in mm
|
567 | 587 | 612 | 633 | 660 | 681 | 700 |
Reach+ in mm
|
433 | 444 | 462 | 479 | 497 | 516 | 536 |
Spacer in mm
|
18 | 18 | 18 | 18 | 18 | 18 | 18 |
---|---|---|---|---|---|---|---|
Cockpit Dimensions in mm
|
80-370 | 90-390 | 90-390 | 100-410 | 110-410 | 110-410 | 120-430 |
Crank Length in mm
|
165,0 | 170,0 | 172,5 | 172,5 | 175,0 | 175,0 | 175,0 |
Chainring Size
|
48/35 | 48/35 | 48/35 | 48/35 | 48/35 | 48/35 | 48/35 |
Seat Post Diameter in mm
|
27,2 | 27,2 | 27,2 | 27,2 | 27,2 | 27,2 | 27,2 |
Seat Post Length in mm
|
345 | 345 | 345 | 345 | 345 | 345 | 345 |
Maximum Seat Post Insertion Depth in mm
|
207 | 207 | 207 | 207 | 207 | 207 | 207 |
Minimum Seat Post Insertion Depth in mm
|
107 | 107 | 107 | 107 | 107 | 107 | 107 |
Wheel Size
|
28" | 28" | 28" | 28" | 28" | 28" | 28" |
Disc Size in mm
|
140 / 140 | 160 / 160 | 160 / 160 | 160 / 160 | 160 / 160 | 160 / 160 | 160 / 160 |
