Inflite CF SL 8
-
Weight:
8.24 kg
WeightWeight is based on a size medium frame.
- Material: Carbon (CF)
-
-
Members only product. Log in here
Highlights Inflite CF SL 8
Frame
-
Frame
- Canyon Inflite CF SL Disc
- Lightweight carbon cyclocross race bike with the same 'cross-specific geometry and design details as the World Championship-winning flagship Inflite models.
- Axle dimension: 12x142 mm
- Tyre clearance: 35 mm
- Material: Carbon (CF)
- Weight: 1,250 g
-
Fork
- Canyon FK0045 CF Disc
- Lightweight carbon fork with the stiffness and strength required for high-level cyclocross racing.
- Axle dimension: 12x100 mm
- Fork steer tube diameter: 1 1/4"
- Tyre clearance: 35 mm
- Material: Carbon (CF)
- Weight: 355 g
Drivetrain
-
Battery
- SRAM Powerpack
-
Rear Derailleur
- SRAM Rival eTap AXS RD 12s
- Weight: 328 g
-
Chainguard
- Canyon EP0703-02 Chainguide with screws
-
Cassette
- SRAM Rival XG-1250, 12-speed, 10-36
- Number of sprockets: 12
- Range: 10-36
-
Crank
- SRAM Rival1 DUB Wide Quarq Powermeter
- Number of chainrings: 1
-
Bottom bracket
- SRAM Pressfit DUB Wide
- Bottom bracket standard: PF 86,5
- Weight: 65 g
-
Chain
- SRAM Rival D1 12s
Brakes
-
Shift-/ Brake Lever
- SRAM Rival eTap AXS 2s
- Weight: 468 g
-
Shift-/ Brake Lever
- SRAM Rival eTap AXS 12s
- Weight: 468 g
-
Brake Rotor
- SRAM Paceline
- Size: 140 mm
- Weight: 159 g
-
Brake Rotor
- SRAM Paceline
- Size: 160 mm
- Weight: 159 g
Wheels
-
Front Wheel
- DT Swiss CRC 1600 Spline
- Axle dimension: 12x100 mm
- Rotor mount: Center Lock
- Rim height: 45 mm
- Weight: 780 g
-
Rear Wheel
- DT Swiss CRC 1600 Spline XDR
- Axle dimension: 12x142 mm
- Rotor mount: Center Lock
- Rim height: 45 mm
- Weight: 925 g
-
Tyre
- Schwalbe X-One Allround TLE
- Width: 33 mm
- Weight: 380 g
-
Thru Axle
- Canyon GP0197-01
- Axle dimension: 12x100 mm
-
Thru Axle
- Canyon GP0235-01
- Axle dimension: 12x142 mm
Cockpit
-
Cockpit
- Canyon H31 Ergocockpit CF
- Carbon one-piece stem-handlebar unit with shorter reach and the 3° flare angle for increased control when riding in the drops.
- Material: Carbon
- Shape: Ergo
- Reach: 70 mm
- Drop: 128 mm
-
Handlebar Tape
- Canyon Ergospeed Gel
- Grippy, durable bar tape with a premium, high-quality, comfortable feel.
- Color: black
Seat
-
Saddle
- Selle Italia SLR Boost
- Gender: Unisex
- Max. Rider Weight: 100 kg
- Weight: 195 g
-
Seatpost
- Canyon SP0042 VCLS CF
- Material: Carbon
- Setback: 8 mm
- Technology: VCLS
Accessories
-
Pedals
- None included
-
Manuals and Accessories
- Canyon Organza Bag
-
Manuals and Accessories
- Canyon Assembly Paste
-
Manuals and Accessories
- Canyon Note about Cockpit Clamp H31
-
Manuals and Accessories
- Canyon Torque Wrench
-
Manuals and Accessories
- Endurace Quick Start Guide
-
Manuals and Accessories
- CAYN SMALL BOX 2.0
Body Height in cm
|
≤ 160 | 160 - 166 | 166 - 172 | 172 - 178 | 178 - 184 | 184 - 190 | 190 - 196 | ≥ 196 |
---|---|---|---|---|---|---|---|---|
Seat Height in mm
(a)
|
613 - 713 | 643 - 743 | 673 - 773 | 703 - 803 | 733 - 833 | 763 - 863 | 793 - 893 | 823 - 923 |
Seat Tube Length in mm
(b)
|
422 | 452 | 482 | 512 | 542 | 572 | 602 | 632 |
Top Tube Length in mm
(c)
|
501 | 522 | 532 | 550 | 562 | 578 | 601 | 617 |
Head Tube Length in mm
(d)
|
94 | 113 | 102 | 119 | 146 | 168 | 192 | 214 |
Head Tube Angle
(e)
|
70,2° | 71,5° | 71° | 72,25° | 72,5° | 72,5° | 72,7° | 72,7° |
Seat Tube Angle
(f)
|
73,5° | 73,5° | 73,5° | 73,5° | 73,5° | 73,5° | 73,5° | 73,5° |
Chainstay Length in mm
(g)
|
415 | 415 | 425 | 425 | 425 | 425 | 425 | 425 |
Wheel Base in mm
(h)
|
970 | 980 | 1.000 | 1.006 | 1.018 | 1.034 | 1.055 | 1.072 |
Stack in mm
(i)
|
487 | 510 | 527 | 547 | 572 | 593 | 616 | 637 |
Reach in mm
(j)
|
357 | 371 | 376 | 388 | 393 | 402 | 418 | 428 |
Stand-over Height in mm
(k)
|
725 | 749 | 783 | 807 | 839 | 859 | 883 | 909 |
Bottom Bracket Offset in mm
(l)
|
55 | 55 | 66 | 66 | 64 | 64 | 64 | 64 |
Stack+ in mm
|
576 | 598 | 618 | 637 | 663 | 686 | 709 | 732 |
Reach+ in mm
|
403 | 419 | 433 | 446 | 462 | 481 | 497 | 517 |
Spacer in mm
|
27,5 | 27,5 | 27,5 | 27,5 | 27,5 | 27,5 | 27,5 | 27,5 |
---|---|---|---|---|---|---|---|---|
Cockpit Dimensions in mm
|
70-380 | 70-400 | 80-420 | 80-420 | 90-420 | 100-440 | 100-440 | 110-460 |
Crank Length in mm
|
165,0 | 165,0 | 170,0 | 170,0 | 172,5 | 175,0 | 175,0 | 175,0 |
Chainring Size
|
40 | 40 | 40 | 40 | 40 | 40 | 40 | 40 |
Seat Post Diameter in mm
|
27,2 | 27,2 | 27,2 | 27,2 | 27,2 | 27,2 | 27,2 | 27,2 |
Seat Post Length in mm
|
350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 |
Maximum Seat Post Insertion Depth in mm
|
207 | 207 | 207 | 207 | 207 | 207 | 207 | 207 |
Minimum Seat Post Insertion Depth in mm
|
107 | 107 | 107 | 107 | 107 | 107 | 107 | 107 |
Wheel Size
|
27.5" | 27.5" | 28" | 28" | 28" | 28" | 28" | 28" |
Disc Size in mm
|
140 / 140 | 140 / 140 | 140 / 140 | 160 / 140 | 160 / 140 | 160 / 140 | 160 / 160 | 160 / 160 |
Inflite CF SL 8 support
Bike classification
Bikes of this category are designed for riding on hard-surface roads where the wheels remain in permanent contact to the ground. These are in general road racing bicycles with racing handlebars or straight handlebars, triathlon or time trial bicycles. The permissible maximum overall weight comprising rider, luggage and bicycle should not exceed 120 kg. Under certain circumstances this permissible maximum weight can be further limited by the component manufacturers’ recommendations for use. Proven cyclocross and gravel bikes with racing handlebars and cantilever or disc brakes are a special case in this category. In addition, these bikes are also suitable for gravel paths and off-road trails where a short loss of tyre contact with the ground due to small stairs or steps at a height of 15 to 20 cm can occur.
Disclaimer
Subject to technical modification without notice. Errors and omissions excepted.
