Endurace 6 RB
-
- Colour: True Blue
-
Members only product. Log in here
Highlights Endurace 6 RB

Top tube rivets

Class-leading geometry

Unisex design
Frame
-
Frame
- Canyon Endurace AL Rim Brake
- Aluminium endurance road bike frame with striking design. Proven comfortable-yet-agile Sport Geometry for fast long-distance riding.
- Tyre clearance: 27 mm
- Material: Aluminium (AL)
- Weight: 1,400 g
-
Fork
- Canyon F25 CF
- Light, stiff carbon road bike fork. Designed for use with rim brakes.
- Fork steer tube diameter: 1 1/4"
- Tyre clearance: 25 mm
- Material: Carbon (CF)
- Weight: 395 g
Drivetrain
-
Rear Derailleur
- Shimano Tiagra R4720
- Cage length: medium
- Weight: 275 g
-
Front Derailleur
- Shimano Tiagra 4700
- Weight: 107 g
-
Cassette
- Shimano HG500 11-34 10s
- Number of sprockets: 10
- Range: 11-34
-
Crank
- Rotor Canyon LTD, 50/34
-
Bottom bracket
- Shimano BSA BB-RS500
- Bottom bracket standard: BSA 68
- Weight: 92 g
-
Chain
- KMC Connection Link 10s
-
Chain
- KMC X10-93 10s
Brakes
-
Brake
- Shimano Tiagra 4700
-
Brake
- Shimano Tiagra 4700
-
Shift-/ Brake Lever
- Shimano Tiagra ST4700
- Weight: 260 g
-
Shift-/ Brake Lever
- Shimano Tiagra ST4700
- Weight: 269 g
Wheels
-
Front Wheel
- Fulcrum Racing 900
- Rotor mount: None
- Rim height: 24 mm
- Weight: 10 g
-
Rear Wheel
- Fulcrum Racing 900
- Rotor mount: None
- Rim height: 24 mm
- Weight: 924 g
-
Tyre
- Continental Grand Prix 5000, 25 mm
- Width: 25 mm
- Weight: 220 g
Cockpit
-
Stem
- Canyon V15
- High-grade aluminium stem
- Clamp diameter: 31.8 mm
- Head tube diameter: 1 1/8”
- Weight: 148 g
-
Handlebar
- Canyon H28 Ergobar AL
- Material: Aluminium
- Shape: Ergo
- Reach: 82 mm
- Drop: 130 mm
-
Handlebar Tape
- Canyon Ergospeed Gel
- Grippy, durable bar tape with a premium, high-quality, comfortable feel.
- Color: black
Seat
-
Saddle
- Selle Italia Model X
- Width: 145 mm
- Gender: Unisex
- Max. Rider Weight: 100 kg
- Weight: 310 g
-
Seatpost
- Iridium Seatpost
- Seatpost diameter: 27,2 mm
- Material: Aluminium (AL)
- Weight: 287 g
-
Seat Clamp
- Canyon Clamp SL
Accessories
-
Pedals
- None included
-
Manuals and Accessories
- Canyon Organza Bag
-
Manuals and Accessories
- Canyon Assembly Paste
-
Manuals and Accessories
- Canyon Torque Wrench
-
Manuals and Accessories
- CAYN SMALL BOX 2.0
Body Height in cm
|
≤ 160 | 160 - 170 | 170 - 177 | 177 - 184 | 184 - 191 | 191 - 197 | ≥ 197 |
---|---|---|---|---|---|---|---|
Seat Height in mm
(a)
|
620 - 720 | 650 - 750 | 680 - 780 | 710 - 810 | 740 - 840 | 770 - 870 | 800 - 900 |
Seat Tube Length in mm
(b)
|
432 | 462 | 492 | 522 | 552 | 582 | 612 |
Top Tube Length in mm
(c)
|
520 | 525 | 539 | 550 | 568 | 593 | 609 |
Head Tube Length in mm
(d)
|
139 | 147 | 164 | 181 | 204 | 230 | 251 |
Head Tube Angle
(e)
|
70,5° | 70,8° | 71,5° | 72,5° | 73,25° | 73,25° | 73,25° |
Seat Tube Angle
(f)
|
73,5° | 73,5° | 73,5° | 73,5° | 73,5° | 73,5° | 73,5° |
Chainstay Length in mm
(g)
|
415 | 415 | 415 | 415 | 415 | 415 | 415 |
Wheel Base in mm
(h)
|
980 | 982 | 990 | 992 | 1.002 | 1.028 | 1.043 |
Stack in mm
(i)
|
540 | 548 | 567 | 587 | 611 | 636 | 656 |
Reach in mm
(j)
|
360 | 363 | 371 | 376 | 387 | 405 | 414 |
Stand-over Height in mm
(k)
|
731 | 751 | 776 | 801 | 828 | 855 | 879 |
Bottom Bracket Offset in mm
(l)
|
70 | 70 | 70 | 70 | 70 | 70 | 70 |
Stack+ in mm
|
634 | 644 | 664 | 684 | 708 | 733 | 754 |
Reach+ in mm
|
404 | 418 | 437 | 453 | 475 | 493 | 512 |
Spacer in mm
|
27,5 | 27,5 | 27,5 | 27,5 | 27,5 | 27,5 | 27,5 |
---|---|---|---|---|---|---|---|
Stem Length in mm
|
80 | 80 | 90 | 100 | 110 | 110 | 120 |
Handlebar Width in mm
|
380 | 400 | 420 | 420 | 420 | 440 | 440 |
Crank Length in mm
|
165,0 | 165,0 | 170,0 | 172,5 | 175,0 | 175,0 | 175,0 |
Chainring Size
|
50/34 | 50/34 | 50/34 | 50/34 | 50/34 | 50/34 | 50/34 |
Seat Post Diameter in mm
|
27,2 | 27,2 | 27,2 | 27,2 | 27,2 | 27,2 | 27,2 |
Seat Post Length in mm
|
330 | 330 | 330 | 330 | 330 | 330 | 330 |
Maximum Seat Post Insertion Depth in mm
|
190 | 190 | 190 | 190 | 190 | 190 | 190 |
Minimum Seat Post Insertion Depth in mm
|
90 | 90 | 90 | 90 | 90 | 90 | 90 |
Wheel Size
|
28" | 28" | 28" | 28" | 28" | 28" | 28" |
Endurace 6 RB support
Bike classification
Bikes of this category are designed for riding on hard-surface roads where the wheels remain in permanent contact to the ground. These are in general road racing bicycles with racing handlebars or straight handlebars, triathlon or time trial bicycles. The permissible maximum overall weight comprising rider, luggage and bicycle should not exceed 120 kg. Under certain circumstances this permissible maximum weight can be further limited by the component manufacturers’ recommendations for use. Proven cyclocross and gravel bikes with racing handlebars and cantilever or disc brakes are a special case in this category. In addition, these bikes are also suitable for gravel paths and off-road trails where a short loss of tyre contact with the ground due to small stairs or steps at a height of 15 to 20 cm can occur.
Disclaimer
Subject to technical modification without notice. Errors and omissions excepted.
