Spectral 29 CF 7

Thanks to its big 29-inch wheels and progressive geometry, the brand-new Spectral 29 CF 7 is faster and more versatile than ever before. More speed, more control: this is your perfect everyday trail bike.

Front Fork Travel: 150 mm
Weight: 14.16 kg

Customer reviews (142)

Colour: Exhaust Black

Members only product.

Select frame size

What’s my size?
Find out in 3 steps

Sold out

Members only product.

Sold out

Highlights Spectral 29 CF 7

Key features

Flip Chip

Do you need maximum stability and control in corners? Or more ground clearance for technical climbing? What if you could have both? Using the Flip Chip on the rear suspension linkage, you can change the bike’s geometry to suit your riding style and riding conditions within a matter of seconds. Head tube and seat tube angle adjustment: 0.5 degrees. Bottom bracket height adjustment: 8 mm.

Replaceable threaded inserts

Inspired by our World Cup mechanics, replaceable threaded inserts guarantee maximum durability. Because if a thread sustains damage after years of hard trail riding, you can just swap it out. And with an ISCG mount you can fit an optional bash guard or chain guide.

Next-level Triple Phase Suspension

The rear end’s Triple Phase Suspension design gives you the performance, control and confidence you need to attack any kind of trail. Sensitive small-bump response provides top traction. In the mid-stroke, a stable feel lets you keep momentum and speed out of berms and over bumps. And on big hits, the suspension ramps up progressively for a bottomless feel.

Components

Content is loading

Frame

Frame
- Canyon Spectral CF 29
- Full-carbon MTB frame. Built to shred with a long, slack, progressive geometry. With Flip Chip system for simple geometry adjustment. Category 4.
- Axle dimension 12x148 mm
- Material Carbon (CF)
- Weight 1,650 g
Rear Shock
- RockShox Deluxe Select+
- Weight 360 g
Suspension Fork
- RockShox Pike Select RC
- Travel 150 mm
- Fork steer tube diameter 1 1/8" - 1,5"
- Weight 1,870 g

Drivetrain

Rear Derailleur
- SRAM GX Eagle
- Cage length long
- Weight 300 g
Chainguard
- Canyon EP1266-01 ISCG05 Plate
Chainguard
- Canyon Chainguide
Shift Lever
- SRAM GX Eagle
- Weight 128 g
Cassette
- SRAM GX Eagle, 12-speed, 10-52T
- Number of sprockets 12
- Range 10-52
Crank
- SRAM GX Eagle, 32T
- Number of chainrings 1
Bottom bracket
- SRAM DUB, Threaded
- Bottom bracket standard BSA 73
- Weight 90 g
Chain
- SRAM SX Eagle 12-speed

Brakes

Disc Brake
- SRAM G2 R
Disc Brake
- SRAM G2 R
Brake Rotor
- SRAM Centerline Rounded
- Size 180 mm
- Weight 168 g
Brake Rotor
- SRAM Centerline
- Size 200 mm
- Weight 190 g

Wheels

Front Wheel
- DT Swiss M 1900
- Rotor mount IS 6-bolt
- Weight 750 g
Rear Wheel
- DT Swiss M 1900 XD
- Rotor mount IS 6-bolt
- Weight 10 g
Tyre
- Maxxis Minion DHF, 2.5"
- Width 2.5"
- Weight 250 g
Tyre
- Maxxis Dissector
- Width 2.4"
- Weight 948 g
Thru Axle
- Canyon Quixle Through Axle QR 148x12
- Axle dimension 12x148 mm

Cockpit

Stem
- Canyon G5
- Modern design, extreme durability Canyon G5 components were developed by our pros on the world's toughest trails.
- Fork steer tube diameter 1 1/8"
- Clamping diameter 31,8 mm
- Material Aluminium (AL)
Handlebar
- Canyon G5
- G5 stands for gravity riding, and category 5. This aluminium bar has superb ergonomics and durability.
- Clamping diameter 31,8 mm
- Width 780 mm
- Rise 30 mm
Grips
- Canyon G5

Seat

Saddle
- Fizik Terra Alpaca X5
- Gender Unisex
- Weight 230 g
Seatpost
- Iridium Dropper Post
- Move more freely on steep descents, by dropping down saddle with the press of a handlebar-mounted button. With internal cabling.
- Seatpost diameter 30,9 mm
- Material Aluminium (AL)
- Weight 567 g
Seat Clamp
- Canyon SC0001

Accessories

Pedals
- None included
Manuals and Accessories
- Canyon Organza Bag
Manuals and Accessories
- Canyon Assembly Paste
Manuals and Accessories
- Canyon Smallbox
Manuals and Accessories
- Canyon Torque Wrench
Manuals and Accessories
- Canyon Shock Pump 300 Psi

Content is loading

Geometry & dimensions

Basic geometry

Detailed geometry table

Body Height in cm	≤ 175	175 - 183	183 - 192	≥ 192
Seat Height in mm (a)	648 - 778	683 - 813	733 - 853	763 - 883
Seat Tube Length in mm (b)	395	430	460	490
Top Tube Length in mm (c)	583	610	637	664
Head Tube Length in mm (d)	95	105	115	125
Head Tube Angle (e)	64,5°	64,5°	64,5°	64,5°
Seat Tube Angle (f)	76°	76°	76°	76°
Chainstay Length in mm (g)	437	437	437	437
Wheel Base in mm (h)	1.197	1.226	1.255	1.285
Stack in mm (i)	615	624	633	642
Reach in mm (j)	431	456	481	506
Stand-over Height in mm (k)	751	758	763	775
Bottom Bracket Offset in mm (l)	33	33	33	33

Component geometry

Detailed geometry table

Spacer in mm	20,0	20,0	20,0	20,0
Stem Length in mm	40	40	40	40
Handlebar Width in mm	760	780	780	780
Crank Length in mm	165,0	170,0	170,0	170,0
Chainring Size	32	32	32	32
Seat Post Diameter in mm	30,9	30,9	30,9	30,9
Dropper post travel in mm	150	150	170	170
Seat Post Length in mm	425	425	465	465
Maximum Seat Post Insertion Depth in mm	220	220	240	240
Minimum Seat Post Insertion Depth in mm	90	90	120	120
Wheel Size	29"	29"	29"	29"
Disc Size in mm	200 / 180	200 / 180	200 / 180	200 / 180
Front Fork Travel in mm	150	150	150	150
Rear Suspension Travel in mm	150	150	150	150
