Inflite CF SLX 9
-
Weight:
7.96 kg
WeightWeight is based on a size medium frame.
- Material: Carbon (CF)
-
Your bike already arrives 95% built. We give you the tools. And simple instructions. No technical skills needed.
-
That’s our quality promise – if you’re not 100% happy with your bike, we’re not happy either.
Learn more
Highlights Inflite CF SLX 9

Special Carbon Fibre Layup

Minimal Mud Surface

Perfectly Balanced
Frame
-
Frame
- Canyon Inflite CF SLX Disc
- Pro-level, 4-time World Championship-winning cyclocross race frame.
- Material: carbon
- Axle dimensions: 12 x 142 mm
- Brake mount: flat mount
- Weight: 940 g
-
Fork
- Canyon FK0045 CF Disc
- Axle dimension: 12x100 mm
- Tyre clearance: 35 mm
- Weight: 362 g
Drivetrain
-
Battery
- SRAM Powerpack
-
Rear Derailleur
- SRAM Force eTap AXS 12s
- Cage length: short
- Weight: 340 g
-
Chainguard
- Canyon EP0703-02 Chainguide with screws
-
Cassette
- SRAM Force XG-1270, 12speed, 10-36
- Number of sprockets: 12
-
Crank
- SRAM Force1 DUB Quarq Powermeter
- Number of chainrings: 1
-
Bottom bracket
- SRAM DUB Pressfit
- Bottom bracket standard: PF 86,5
- Weight: 67 g
-
Chain
- SRAM Force D1 12s
Brakes
-
Shift-/ Brake Lever
- SRAM Force eTap AXS HRD 2s
- Weight: 605 g
-
Shift-/ Brake Lever
- SRAM Force eTap AXS HRD 12s
- Weight: 610 g
-
Brake Rotor
- SRAM Centerline X Rounded Edges
- Size: 140 mm
- Weight: 103 g
-
Brake Rotor
- SRAM Centerline, 160mm
- Size: 160 mm
- Weight: 117 g
Wheels
-
Front Wheel
- Reynolds AR41 DB
- Rotor mount: Center Lock
- Weight: 800 g
-
Rear Wheel
- Reynolds AR41 DB XD-R
- Rotor mount: Center Lock
- Rim height: 41 mm
- Weight: 840 g
-
Tyre
- Schwalbe X-One Allround TLE
- Width: 33 mm
- Weight: 380 g
-
Thru Axle
- Canyon Through Axle
- Axle dimension: 12x100 mm
- Material: Aluminium (AL)
-
Thru Axle
- Canyon Thru Axle
- Axle dimension: 12x142 mm
Cockpit
-
Cockpit
- Canyon H31 Ergocockpit CF
- Carbon one-piece stem-handlebar unit with shorter reach and the 3° flare angle for increased control when riding in the drops.
- Material: Carbon
- Shape: Ergo
- Reach: 70 mm
- Drop: 128 mm
-
Handlebar Tape
- Canyon Ergospeed Gel
- Grippy, durable bar tape with a premium, high-quality, comfortable feel.
- Color: black
Seat
-
Saddle
- Selle Italia SLR Boost
- Gender: Unisex
- Max. Rider Weight: 100 kg
- Weight: 195 g
-
Seatpost
- Canyon S14 VCLS 2.0 CF
- Material: Carbon
- Setback: -2 mm / 10 mm
- Technology: VCLS 2.0 | Fliphead
- Weight: 220 g
Accessories
-
Pedals
- None included
-
Manuals and Accessories
- Canyon Organza Bag
-
Manuals and Accessories
- Canyon Assembly Paste
-
Manuals and Accessories
- BAG REY Acc Assault LE 21C C DB
-
Manuals and Accessories
- Canyon Note about Cockpit Clamp H31
-
Manuals and Accessories
- Canyon Torque Wrench
-
Manuals and Accessories
- Endurace Quick Start Guide
-
Manuals and Accessories
- CAYN SMALL BOX 2.0
Body Height in cm
|
≤ 160 | 160 - 166 | 166 - 172 | 172 - 178 | 178 - 184 | 184 - 190 | 190 - 196 | ≥ 196 |
---|---|---|---|---|---|---|---|---|
Seat Height in mm
(a)
|
613 - 713 | 643 - 743 | 673 - 773 | 703 - 803 | 733 - 833 | 763 - 863 | 793 - 893 | 823 - 923 |
Seat Tube Length in mm
(b)
|
422 | 452 | 482 | 512 | 542 | 572 | 602 | 632 |
Top Tube Length in mm
(c)
|
501 | 522 | 532 | 550 | 562 | 578 | 601 | 617 |
Head Tube Length in mm
(d)
|
94 | 113 | 102 | 119 | 146 | 168 | 192 | 214 |
Head Tube Angle
(e)
|
70,2° | 71,5° | 71° | 72,25° | 72,5° | 73,5° | 72,7° | 72,7° |
Seat Tube Angle
(f)
|
73,5° | 73,5° | 73,5° | 73,5° | 73,5° | 73,5° | 73,5° | 73,5° |
Chainstay Length in mm
(g)
|
415 | 415 | 425 | 425 | 425 | 425 | 425 | 425 |
Wheel Base in mm
(h)
|
970 | 980 | 1.000 | 1.006 | 1.018 | 1.034 | 1.055 | 1.072 |
Stack in mm
(i)
|
487 | 510 | 527 | 547 | 572 | 593 | 616 | 637 |
Reach in mm
(j)
|
357 | 371 | 376 | 388 | 393 | 402 | 418 | 428 |
Stand-over Height in mm
(k)
|
725 | 749 | 783 | 807 | 839 | 859 | 883 | 909 |
Bottom Bracket Offset in mm
(l)
|
55 | 55 | 66 | 66 | 64 | 64 | 64 | 64 |
Stack+ in mm
|
576 | 598 | 618 | 637 | 663 | 686 | 709 | 732 |
Reach+ in mm
|
403 | 419 | 433 | 446 | 462 | 481 | 497 | 517 |
Spacer in mm
|
27,5 | 27,5 | 27,5 | 27,5 | 27,5 | 27,5 | 27,5 | 27,5 |
---|---|---|---|---|---|---|---|---|
Cockpit Dimensions in mm
|
70-380 | 70-400 | 80-420 | 80-420 | 90-420 | 100-440 | 100-440 | 110-460 |
Crank Length in mm
|
165,0 | 165,0 | 170,0 | 170,0 | 172,5 | 175,0 | 175,0 | 175,0 |
Chainring Size
|
40 | 40 | 40 | 40 | 40 | 40 | 40 | 40 |
Seat Post Diameter in mm
|
27,2 | 27,2 | 27,2 | 27,2 | 27,2 | 27,2 | 27,2 | 27,2 |
Seat Post Length in mm
|
350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 |
Maximum Seat Post Insertion Depth in mm
|
207 | 207 | 207 | 207 | 207 | 207 | 207 | 207 |
Minimum Seat Post Insertion Depth in mm
|
107 | 107 | 107 | 107 | 107 | 107 | 107 | 107 |
Wheel Size
|
27.5" | 27.5" | 28" | 28" | 28" | 28" | 28" | 28" |
Disc Size in mm
|
140 / 140 | 140 / 140 | 140 / 140 | 160 / 140 | 160 / 140 | 160 / 140 | 160 / 160 | 160 / 160 |
Inflite CF SLX 9 support
Bike classification
Bikes of this category are designed for riding on hard-surface roads where the wheels remain in permanent contact to the ground. These are in general road racing bicycles with racing handlebars or straight handlebars, triathlon or time trial bicycles. The permissible maximum overall weight comprising rider, luggage and bicycle should not exceed 120 kg. Under certain circumstances this permissible maximum weight can be further limited by the component manufacturers’ recommendations for use. Proven cyclocross and gravel bikes with racing handlebars and cantilever or disc brakes are a special case in this category. In addition, these bikes are also suitable for gravel paths and off-road trails where a short loss of tyre contact with the ground due to small stairs or steps at a height of 15 to 20 cm can occur.
Disclaimer
Subject to technical modification without notice. Errors and omissions excepted.
