Speedmax CF 8.0 Di2

Name: Speedmax CF 8.0 Di2
Brand: Canyon
Price: 4299.00 USD
Availability: OutOfStock
Rating: 5 (47 reviews)

Combining a Shimano Ultegra Di2 groupset with impressive DT Swiss ARC 1400 Dicut wheels, and an outstanding aerodynamic frame with race proven geometry, this bike will help you reach your full potential.

Customer reviews (47)

Colour: Stealth

Members only product.

Select frame size

What’s my size?
Find out in 3 steps

Hint: Use our recommendation and get the correct size first time.

Sold out

Members only product.

Sold out

Highlights Speedmax CF 8.0 Di2

Components

Content is loading

Frame

Frame
- Canyon Speedmax CF
- Material Carbon
- Axle Dimension 9 x 130 mm
- Brake Mount Direct Mount
Fork
- Canyon F39 CF
- Fork steer tube diameter 1 1/8"
- Material Carbon (CF)
- Weight 390 g
Headset
- Tange IS-22AE-SCT

Drivetrain

Battery
- Shimano BT-DN110 Di2 Battery
Rear Derailleur
- Shimano Ultegra Di2 R8050 SS
- Cage length short
- Weight 10 g
Front Derailleur
- Shimano Ultegra Di2 R8050
- Weight 132 g
Shift Lever
- Shimano Di2 Remote TT right
- Weight 50 g
Shift Lever
- Shimano Di2 Remote TT left
- Weight 10 g
Shift Lever
- Shimano Ultegra Di2 R8060 TT 2s
- Weight 137 g
Shift Lever
- Shimano Ultegra Di2 R8060 TT 11s
- Weight 156 g
Cassette
- Shimano Ultegra R8000, 11-speed, 11-28T
- Number of sprockets 11
Crank
- Shimano Ultegra R8000
- Number of chainrings 2
Bottom bracket
- Shimano Pressfit BB72
- Bottom bracket standard PF 86,5
- Weight 65 g
Chain
- Shimano HG701 11-speed
- High-grade chain with premium SIL-TEC treatment on roller link plate and pin link plate for increased durability and efficiency.

Brakes

Brake
- Shimano Ultegra R8010
Brake
- Shimano Ultegra R8010

Wheels

Front Wheel
- DT Swiss ARC 1400 Dicut
- Rotor mount Center Lock
Rear Wheel
- DT Swiss ARC 1400 Dicut db S11
- Rotor mount Center Lock
- Weight 953 g
Tyre
- Continental Grand Prix 5000 / Attack 23 mm
- Width 23 mm
- Weight 210 g
Tyre
- Continental Grand Prix 5000, 25 mm
- Width 25 mm
- Weight 220 g

Cockpit

Stem
- Canyon V21
- Exclusively designed for our Speedmax CF range.
- Angle -17°
- Clamping diameter 31.8 mm,
- Weight 199 g
Stem
- ST CAYN E428-16 Front Plate V21 bk
Handlebar
- Canyon H30 Basebar Flat CF
- Triathlon handlebar featuring the Subsonic Bracket Kit from Profile Design
- Type Flat
- Basebar Rise 0 mm
Aero Bar
- Profile Design Subsonic Race 35a
Handlebar Tape
- Canyon Ergospeed Gel
- Grippy, durable bar tape with a premium, high-quality, comfortable feel.
- Color black

Seat

Saddle
- Fizik Mistica
- Weight 235 g
Seatpost
- Canyon S31 TRI CF
- Material Carbon
- Setback Adjustable
- Technology Fliphead
- Interface Canyon Bottle Cage Adapter Mount
Seat Clamp
- Canyon Seatclamp for S31/S32

Accessories

Pedals
- None included
Manuals and Accessories
- Canyon Assembly Paste
Manuals and Accessories
- DT Swiss warranty & intended use manual
Manuals and Accessories
- Canyon Starter Box
Manuals and Accessories
- Canyon Torque Wrench
Manuals and Accessories
- Endurace Quick Start Guide

Content is loading

Geometry & dimensions

Basic geometry

Detailed geometry table

Body Height in cm	≤ 165	165 - 175	175 - 185	185 - 195	≥ 195
Seat Height in mm (a)	599 - 729	628 - 758	731 - 861	753 - 883	781 - 911
Seat Tube Length in mm (b)	491	520	543	565	593
Top Tube Length in mm (c)	477	490	514	528	552
Head Tube Length in mm (d)	75	104	128	151	179
Head Tube Angle (e)	72,5°	73°	73°	73°	73°
Seat Tube Angle (f)	80,5°	80,5°	80,5°	80,5°	80,5°
Chainstay Length in mm (g)	420	420	420	420	420
Wheel Base in mm (h)	981	994	1.020	1.037	1.066
Stack in mm (i)	481	510	533	555	582
Reach in mm (j)	397	405	425	435	455
Bottom Bracket Offset in mm (l)	70	70	70	70	70
Armpad Stack in mm (m)	553 - 640	582 - 669	605 - 692	627 - 714	654 - 741
Armpad Reach in mm (n)	430 - 455	447 - 472	467 - 492	488 - 513	508 - 533

Component geometry

Detailed geometry table

Spacer in mm	87,0	87,0	87,0	87,0	87,0
Stem Length in mm	70	80	80	90	90
Handlebar Width in mm	410	410	410	410	410
Crank Length in mm	172,5	172,5	175,0	175,0	175,0
Chainring Size	52/36	52/36	52/36	52/36	52/36
Seat Post Length in mm	270	270	350	350	350
Maximum Seat Post Insertion Depth in mm	210	210	210	210	210
Minimum Seat Post Insertion Depth in mm	80	80	80	80	80
Wheel Size	28"	28"	28"	28"	28"

Download PDF

Content is loading

Speedmax CF 8.0 Di2 support

⚠︎ WARNING

Risk of cancer and reproductive harm from exposure to lead. See www.P65Warnings.ca.gov

Production Variations

We strive for complete accuracy with our technical specifications. However, specifications are subject to change without notice. Variation between posted information and actual specification does not warrant any changes, modifications, or exchanges to any products affected by a variation. If we may provide further details, please contact our Canyon USA Service Team.
