Grizl 7
When the asphalt ends, the Grizl 7 comes alive. This progressive all-round gravel bike can truly do it all –from day-in-day-out commuting, to quick gravel microadventures, to multi-day bikepacking epics.
-
-
Members only product. Log in here
Select frame size
Hint: Use our recommendation and get the correct size first time.
Sold out
Members only product.
Log in here
Sold out
Highlights Grizl 7

Rigged for racks
Take all the gear you could ever need with a rear pannier rack. From summer bikepacking or winter commuting, the Grizl AL can bear the load.

Refined aluminium frame
The Grizl pairs its sleek lines with clean, precise welding for incredible aesthetics at an attainable price point.

Fork mounts
Securely bolt on a couple of Anything Cages to your fork, and carry extra bottles, clothing, or even a tent on your adventure with you.
Content is loading
Frame
-
Frame
- Canyon Grizl AL
- Aluminium frame with Gravel Pro geometry, a range of mounting points, and extended wheelbase for extra off-road stability.
- Axle dimension: 12x142 mm
- Tyre clearance: 50 mm
- Material: Aluminium (AL)
- Weight: 1,200 g
-
Fork
- Canyon FK0087 CF Disc
- Light, robust carbon frame with 3-screw mounting points on each side for attaching bottle cages and Anything Cages.
- Axle dimension: 12x100 mm
- Fork steer tube diameter: 1 1/4"
- Tyre clearance: 54 mm
- Material: Carbon (CF)
- Weight: 750 g
Drivetrain
-
Rear Derailleur
- Shimano GRX RX810 GS
- Cage length: long
- Weight: 252 g
-
Front Derailleur
- Shimano GRX RX810
- Max chainring gear range: 17T.
- Weight: 101 g
-
Cassette
- Shimano HG700 11-34 11s
- Number of sprockets: 11
-
Crank
- Shimano RX600
- Number of chainrings: 2
-
Bottom bracket
- Token Ninja Lite BB4124
- Bottom bracket standard: PF 86,5
- Weight: 85 g
-
Chain
- Shimano CN-HG601 11s
- Chain featuring SIL-TEC ultra-low friction surface treatment for precise shifting and improved durability.
Brakes
-
Shift-/ Brake Lever
- Shimano GRX RX600, 2s
- Weight: 541 g
-
Shift-/ Brake Lever
- Shimano GRX RX600 11s
- Weight: 541 g
-
Brake Rotor
- Shimano RT70
- Size: 160 mm
- Weight: 150 g
Wheels
-
Front Wheel
- DT Swiss Gravel LN
- Axle dimension: 12x100 mm
- Rotor mount: Center Lock
- Rim height: 25 mm
- Inner width: 24 mm
- Rim material: Aluminium
- Weight: 946 g
-
Rear Wheel
- WH DT GR LN CLA27.5 12X142 25 CL S11
- Axle dimension: 12x142 mm
- Rotor mount: Center Lock
- Rim height: 25 mm
- Weight: 928 g
-
Tyre
- Maxxis Rambler 45 mm
-
Thru Axle
- Canyon GP0197-01
- Axle dimension: 12x100 mm
-
Thru Axle
- Canyon GP0235-01
- Axle dimension: 12x142 mm
Cockpit
-
Stem
- Canyon V13
- High-quality aluminium stem with square cross-sectional profile. A new handlebar clamp design increases torsional stiffness by up to 40%. Handlebar clamp diameter: 31.8 mm. Head tube diameter: 1 1/4".
- Fork steer tube diameter: 1 1/4"
- Clamping diameter: 31,8 mm
-
Handlebar
- Canyon HB0063 Ergo AL
- Clamping diameter: 31,8 mm
- Width: 420 mm
-
Handlebar Tape
- Canyon Ergospeed Gel
- Grippy, durable bar tape with a premium, high-quality, comfortable feel.
- Color: black
Seat
-
Saddle
- WTB Volt Steel
-
Seatpost
- Canyon SP0057 VCLS
- With vibration-absorbing design for top rear-end comfort.
- Setback: 20 mm
- Seatpost diameter: 27,2 mm
- Material: Carbon (CF)
- Weight: 265 g
-
Seat Clamp
- Canyon Clamp SL
Accessories
-
Pedals
- None included
-
Manuals and Accessories
- Canyon Organza Bag
-
Manuals and Accessories
- Canyon Assembly Paste
-
Manuals and Accessories
- Canyon Starter Box
-
Manuals and Accessories
- Canyon Torque Wrench
-
Manuals and Accessories
- Endurace Quick Start Guide
-
Manuals and Accessories
- Canyon Quick Start Guide
Content is loading
Content is loading
Body Height in cm
|
≤ 158 | 158 - 166 | 166 - 172 | 172 - 178 | 178 - 184 | 184 - 189 | 189 - 194 | ≥ 194 |
---|---|---|---|---|---|---|---|---|
Seat Height in mm
(a)
|
593 - 693 | 623 - 723 | 653 - 753 | 683 - 783 | 713 - 813 | 743 - 843 | 773 - 873 | 803 - 903 |
Seat Tube Length in mm
(b)
|
402 | 432 | 462 | 492 | 522 | 552 | 582 | 612 |
Top Tube Length in mm
(c)
|
524 | 532 | 541 | 562 | 574 | 588 | 612 | 627 |
Head Tube Length in mm
(d)
|
115 | 122 | 135 | 121 | 141 | 166 | 186 | 205 |
Head Tube Angle
(e)
|
69° | 69,75° | 70,5° | 70,25° | 71,5° | 72° | 72,5° | 72,5° |
Seat Tube Angle
(f)
|
73,5° | 73,5° | 73,5° | 73,5° | 73,5° | 73,5° | 73,5° | 73,5° |
Chainstay Length in mm
(g)
|
420 | 420 | 420 | 435 | 435 | 435 | 435 | 435 |
Wheel Base in mm
(h)
|
1.007 | 1.009 | 1.012 | 1.044 | 1.045 | 1.055 | 1.074 | 1.089 |
Stack in mm
(i)
|
512 | 522 | 537 | 556 | 579 | 605 | 626 | 644 |
Reach in mm
(j)
|
372 | 377 | 382 | 397 | 402 | 409 | 427 | 436 |
Stand-over Height in mm
(k)
|
709 | 730 | 752 | 780 | 807 | 835 | 860 | 884 |
Bottom Bracket Offset in mm
(l)
|
60 | 60 | 60 | 75 | 75 | 75 | 75 | 75 |
Stack+ in mm
|
602 | 612 | 626 | 645 | 670 | 697 | 717 | 738 |
Reach+ in mm
|
417 | 423 | 429 | 444 | 460 | 477 | 496 | 515 |
Spacer in mm
|
18 | 18 | 18 | 18 | 18 | 18 | 18 | 18 |
---|---|---|---|---|---|---|---|---|
Stem Length in mm
|
70 | 70 | 80 | 80 | 80 | 90 | 90 | 100 |
Handlebar Width in mm
|
380 | 400 | 400 | 420 | 420 | 440 | 460 | 460 |
Crank Length in mm
|
170,0 | 170,0 | 170,0 | 172,5 | 172,5 | 175,0 | 175,0 | 175,0 |
Chainring Size
|
46/30 | 46/30 | 46/30 | 46/30 | 46/30 | 46/30 | 46/30 | 46/30 |
Seat Post Diameter in mm
|
27,2 | 27,2 | 27,2 | 27,2 | 27,2 | 27,2 | 27,2 | 27,2 |
Seat Post Length in mm
|
350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 |
Maximum Seat Post Insertion Depth in mm
|
207 | 207 | 207 | 207 | 207 | 207 | 207 | 207 |
Minimum Seat Post Insertion Depth in mm
|
107 | 107 | 107 | 107 | 107 | 107 | 107 | 107 |
Wheel Size
|
27.5" | 27.5" | 27.5" | 28" | 28" | 28" | 28" | 28" |
Disc Size in mm
|
160 / 160 | 160 / 160 | 160 / 160 | 160 / 160 | 160 / 160 | 160 / 160 | 160 / 160 | 160 / 160 |
Download PDF
Grizl 7 support
Proposition 65 Warning
Warning: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
Production Variations
We strive for complete accuracy with our technical specifications. However, specifications are subject to change without notice. Variation between posted information and actual specification does not warrant any changes, modifications, or exchanges to any products affected by a variation. If we may provide further details, please contact our Canyon USA Service Team.
