Neuron CF 6 WMN

Leave the streets behind and seek out off-road adventure! Whether you ride in the forest, the mountains or the desert, the trails are calling and the Neuron CF 6 WMN, with its women’s-specific components and all-around, full-suspension performance, is ready to go!

Front Fork Travel: 140 mm
Weight: 29.99 lbs

Colour: Tide Grey

Members only product.

Select frame size

What’s my size?
Find out in 3 steps

Hint: Use our recommendation and get the correct size first time.

Sold out

Members only product.

Sold out

Highlights Neuron CF 6 WMN

Components

Frame

Frame
- Canyon Neuron CF
- Material Carbon (CF)
Rear Shock
- RockShox Deluxe Select+
- Weight 360 g
Suspension Fork
- Rock Shox Pike Select
- Travel 140 mm
- Fork steer tube diameter 1 1/8" - 1,5"
- Weight 1,870 g

Drivetrain

Rear Derailleur
- SRAM GX Eagle
- Cage length long
- Weight 300 g
Shift Lever
- SRAM NX Eagle Trigger 12s
- Weight 128 g
Cassette
- SRAM GX Eagle, 12-speed, 10-52T
- Number of sprockets 12
- Range 10-52
Crank
- Truvativ Stylo 6K DUB 30T
- Number of chainrings 1
Bottom bracket
- SRAM BSA DUB
- Bottom bracket standard BSA 73
- Weight 86 g
Chain
- SRAM NX Eagle 12s

Brakes

Disc Brake
- SRAM G2 RS
Disc Brake
- SRAM G2 RS
Brake Rotor
- SRAM Centerline Rounded
- Size 180 mm
- Weight 168 g
Brake Rotor
- SRAM Centerline
- Size 200 mm
- Weight 190 g

Wheels

Front Wheel
- DT Swiss M 1900
- Rotor mount IS 6-bolt
- Weight 750 g
Rear Wheel
- DT Swiss M 1900 XD
- Rotor mount IS 6-bolt
- Weight 10 g
Tyre
- Maxxis Dissector
- Width 2.4"
- Weight 948 g
Tyre
- MAXXIS Rekon 2.4"
- Width 2.4"
Thru Axle
- Canyon Quixle Thru Axle, Boost 148

Cockpit

Grips
- Ergon GA20

Seat

Saddle
- Ergon SM10 Sport Women
- Weight 290 g
Seatpost
- Iridium Dropper Post
- Move more freely on steep descents, by dropping down saddle with the press of a handlebar-mounted button. With internal cabling.
- Seatpost diameter 30,9 mm
- Material Aluminium (AL)
- Weight 567 g

Accessories

Pedals
- None included
Manuals and Accessories
- Canyon Assembly Paste
Manuals and Accessories
- Canyon Smallbox
Manuals and Accessories
- Canyon Torque Wrench
Manuals and Accessories
- Canyon Shock Pump 300 Psi

Content is loading

Geometry & dimensions

Basic geometry

Detailed geometry table

Body Height in cm	≤ 165	165 - 174	≥ 174
Seat Height in mm (a)	627 - 736	653 - 783	698 - 828
Seat Tube Length in mm (b)	400	400	445
Top Tube Length in mm (c)	558	581	603
Head Tube Length in mm (d)	88	100	102
Head Tube Angle (e)	67°	67°	67,5°
Seat Tube Angle (f)	74,5°	74,5°	74,5°
Chainstay Length in mm (g)	430	430	440
Wheel Base in mm (h)	1.121	1.146	1.167
Stack in mm (i)	578	589	614
Reach in mm (j)	398	418	433
Stand-over Height in mm (k)	758	762	780
Bottom Bracket Offset in mm (l)	18	18	38

Component geometry

Detailed geometry table

Spacer in mm	5,0	5,0	10,0
Crank Length in mm	170,0	170,0	175,0
Chainring Size	30	30	30
Seat Post Diameter in mm	30,9	30,9	30,9
Dropper post travel in mm	125	150	150
Seat Post Length in mm	378	425	425
Maximum Seat Post Insertion Depth in mm	199	220	220
Minimum Seat Post Insertion Depth in mm	90	90	90
Wheel Size	27.5"		29"
Disc Size in mm	200 / 180	200 / 180	200 / 180
Front Fork Travel in mm	140	140	140
Rear Suspension Travel in mm	130	130	130
Fitting Length	210X50	210X50	210X50

Download PDF

Neuron CF 6 WMN support

⚠︎ WARNING

Risk of cancer and reproductive harm from exposure to lead. See www.P65Warnings.ca.gov

Production Variations

We strive for complete accuracy with our technical specifications. However, specifications are subject to change without notice. Variation between posted information and actual specification does not warrant any changes, modifications, or exchanges to any products affected by a variation. If we may provide further details, please contact our Canyon USA Service Team.
