Neuron CF SLX 9

All components

Product Configuration

Colour:

Visible Black

Members only product.

Select frame size

What’s my size?
Find out in 3 steps

Hint: Use our recommendation and get the correct size first time.

Sold out

Members only product.

Buying reasons

Sold out

Highlights Neuron CF SLX 9

Components

All components are based on size M

Frame

Frame
- Canyon Neuron CF SLX
- null
- null
Rear Shock
- FOX Float DPS Factory
- null
Suspension Fork
- FOX 34 Factory
- null
- null
- null

Drivetrain

Rear Derailleur
- Shimano XTR, 12-speed
- null
- null
Shift Lever
- Shimano XTR, 12-speed
- null
Cassette
- Shimano Deore XT CS-M8100
- null
- null
Crank
- Race Face Next SL G5 Carbon 32T
- null
Bottom bracket
- Race Face BSA Cinch
- null
- null
Chain
- Shimano XT

Brakes

Disc Brake
- Shimano XTR M9120
Disc Brake
- Shimano XTR M9120
Brake Rotor
- Shimano RT-MT900, 180mm
- null
- null

Wheels

Front Wheel
- DT Swiss XMC 1200
- null
- null
Rear Wheel
- DT Swiss XMC 1200
- null
- null
Tyre
- Maxxis Dissector
- null
- null
Tyre
- MAXXIS Rekon 2.4"
- null
Thru Axle
- Canyon Quixle Thru Axle, Boost 148

Cockpit

Stem
- Race Face Turbine 35
- null
Handlebar
- Race Face Next 35
- null
Grips
- Ergon GA20

Seat

Saddle
- Ergon SM10 Sport Men
- null
- null
Seatpost
- FOX Transfer Factory
- null
- null

Accessories

Pedals
- None included
Manuals and Accessories
- Canyon Assembly Paste
Manuals and Accessories
- Canyon Smallbox
Manuals and Accessories
- Canyon Torque Wrench
Manuals and Accessories
- Canyon Shock Pump 300 Psi

Content is loading

Geometry & dimensions

Basic geometry

Detailed geometry table
Frame size
Body Height in cm	≤ 182	182 - 192	≥ 192
a Seat Height in mm	704 - 849	739 - 884	779 - 924
b Seat Tube Length in mm	445	480	520
c Top Tube Length in mm	603	626	654
d Head Tube Length in mm	102	112	143
e Head Tube Angle	67,5°	67,5°	67,5°
f Seat Tube Angle	74,5°	74,5°	74,5°
g Chainstay Length in mm	440	440	440
h Wheel Base in mm	1.167	1.190	1.222
i Stack in mm	614	623	651
j Reach in mm	433	453	473
k Stand-over Height in mm	780	780	796
l Bottom Bracket Offset in mm	38	38	38

Component geometry

Detailed geometry table
Frame size
Spacer in mm	10,0	15,0	15,0
Stem Length in mm	60	60	60
Handlebar Width in mm	760	760	760
Crank Length in mm	175,0	175,0	175,0
Chainring Size	32	32	32
Seat Post Diameter in mm	30,9	30,9	30,9
Dropper post travel in mm	150	150	150
Seat Post Length in mm	456	456	456
Maximum Seat Post Insertion Depth in mm	245	245	245
Minimum Seat Post Insertion Depth in mm	100	100	100
Wheel Size	29"	29"	29"
Disc Size in mm	180 / 180	180 / 180	180 / 180
Front Fork Travel in mm	130	130	130
Rear Suspension Travel in mm	130	130	130
Fitting Length	210X50	210X50	210X50

Download PDF

Neuron CF SLX 9 support

⚠︎ WARNING

Risk of cancer and reproductive harm from exposure to lead. See www.P65Warnings.ca.gov

Production Variations

We strive for complete accuracy with our technical specifications. However, specifications are subject to change without notice. Variation between posted information and actual specification does not warrant any changes, modifications, or exchanges to any products affected by a variation. If we may provide further details, please contact our Canyon USA Service Team.
