US Spectral:ON CF 8

Out of stock

$4,799

Financing available for this product

Simply the best value in trail e-MTBs today. Full carbon frame, stellar components, and a price that just can’t be beat.

Bomber-yet-lightweight, full-carbon frame
Proven power, courtesy of Shimano EP8 motor
Reliable FOX 38 Rhythm fork and Float X shock
Durable Shimano XT/SLX drivetrain and brakes
Rugged, removable 800 Wh aluminium battery
Up to 85 km range and 1,900 m of elevation gain

Weight: 53.80 lbs
Material: Carbon (CF)

Colour: Eternal Blue

Members only product.

Frame Size: M

Members only product.

$4,799

Financing available for this product

Delivery: Select batch number

Additional information

Current delivery times information. Read more

Financing with Affirm Financing

Financing available for this product

Financing with Klarna

Financing with PayPal
Get ready-to-ride Delivery

Ready to ride delivery with velofix DIRECT

With velofix DIRECT, you can schedule delivery directly to your home or office. A professional technician can deliver, build, and dial in your new bike.

Collect & Ride

Nervous about building your new bike? Have your bike sent directly to your local bike shop to be assembled by an expert. Collect your bike at a time that suits you.
How to choose Collect & Ride
6 Year Warranty on all Canyon-manufactured parts (frame, road bike fork, cockpit, etc.)
Learn More
Your bike arrives in our custom Bike Guard – built to absorb impacts in transit and keep every component locked in place. Tough, reusable, and ready to double as a stable stand for a fast setup.

Delivery: Select batch number

Highlights US Spectral:ON CF 8

Components

Frame

Frame
- Canyon Spectral:ON CF
- Carbon frame with integrated battery. Category 4e.
- Material Carbon (CF)
- Weight 1,000 g
Rear Shock
- Fox DPS Performance Evolution
- Weight 506 g
Suspension Fork
- Fox 36 Rhythm Grip
- Travel 150 mm
- Fork steer tube diameter 1 1/8" - 1,5"
Seatpost Clamp
- Canyon GP0279-01 Seatclamp

Drivetrain

Motor
- Shimano EP801
Battery
- Canyon BT010
Rear Derailleur
- Shimano Deore XT M8100
- Cage length long
- Weight 282 g
Chainguard
- Canyon Chainguide M091/M129
Shift Lever
- Shimano Deore SLX M7100
- Weight 143 g
Cassette
- Shimano Deore M6100
- Number of sprockets 12
- Range 10-51
Crank
- Shimano Steps
- Number of chainrings 1
Chainring
- Canyon EP1110-01 Chainring 34T
Chain
- Shimano Deore M6100

Brakes

Disc Brake
- Shimano SLX M7120
Disc Brake
- Shimano SLX M7120
- Number of pistons 4
Brake Rotor
- Hayes D-Series
- Size 203 mm
- Weight 188 g

Wheels

Front Wheel
- SunRingle Düroc SD37 Comp 29"
- Axle dimension 15x110 mm
- Rotor mount IS 6-bolt
- Rim material Aluminium
- Weight 1,118 g
Rear Wheel
- SunRingle Duroc SD42 12x148
- Axle dimension 12x148 mm
- Rotor mount IS 6-bolt
- Rim material Aluminium
- Weight 1,306 g
Tyre
- Maxxis Assegai
- Width 2.5"
- Weight 1,072 g
Tyre
- Maxxis Minion DHR II 27,5" x 2.60 WT
- Width 2.6"
- Weight 900 g
Thru Axle
- Canyon Quixle
- Axle dimension 12x148 mm

Cockpit

Stem
- Canyon:ON ST0031
- Canyon E-MTB stem.
- Length 45 mm
- Fork steer tube diameter 1 1/8"
- Clamping diameter 35,0 mm
- Material Aluminium (AL)
Handlebar
- Canyon:ON HB0057 Riser bar
- Canyon-developed E-MTB handlebar for top control levels on the trail.
- Clamping diameter 35,0 mm
- Rise 30 mm
Grips
- Canyon Lock-On

Seat

Saddle
- Fizik Terra Aidon X5
- Gender Unisex
- Weight 272 g
Seatpost
- Iridium Dropper Post
- Move more freely on steep descents, by dropping down saddle with the press of a handlebar-mounted button. With internal cabling.
- Seatpost diameter 30,9 mm
- Material Aluminium (AL)
- Weight 567 g

Light

Lights
- Reflector Set

Accessories

Battery Charger
- Canyon BC001
Pedals
- Flat Pedals
Manuals and Accessories
- Canyon Organza Bag
Manuals and Accessories
- Wrench Tool 15mm
Manuals and Accessories
- Canyon Assembly Paste
Manuals and Accessories
- Canyon Torque Wrench
Manuals and Accessories
- Canyon Quick Start Guide Spectral:ON
Manuals and Accessories
- Pedelec Manual 005-V04
Manuals and Accessories
- Canyon Smallbox
Manuals and Accessories
- Canyon Shock Pump 300 Psi

Content is loading

Geometry & dimensions

Basic geometry

Detailed geometry table
Frame size
Body Height in cm	≤ 175	175 - 183	183 - 192	≥ 192
a Seat Height in mm	647 - 756	693 - 823	733 - 853	753 - 873
b Seat Tube Length in mm	420	440	460	480
c Top Tube Length in mm	589	613	637	663
d Head Tube Length in mm	115	125	135	145
e Head Tube Angle	65,5°	65,5°	65,5°	65,5°
f Seat Tube Angle	76,5°	76,5°	76,5°	76,5°
g Chainstay Length in mm	440	440	440	440
h Wheel Base in mm	1.194	1.223	1.252	1.281
i Stack in mm	634	643	652	661
j Reach in mm	435	460	485	510
k Stand-over Height in mm	809	814	820	825
l Bottom Bracket Offset in mm	36	36	36	36

Component geometry

Detailed geometry table
Frame size
Spacer in mm	15,0	15,0	15,0	15,0
Stem Length in mm	45	45	45	45
Handlebar Width in mm	760	780	780	780
Crank Length in mm	165,0	165,0	165,0	165,0
Chainring Size	34	34	34	34
Seat Post Diameter in mm	30,9	30,9	30,9	30,9
Dropper post travel in mm	125	150	170	170
Seat Post Length in mm	378	425	465	465
Maximum Seat Post Insertion Depth in mm	199	220	240	240
Minimum Seat Post Insertion Depth in mm	90	90	120	120
Wheel Size	29"/27.5"	29"/27.5"	29"/27.5"	29"/27.5"
Disc Size in mm	203 / 203	203 / 203	203 / 203	203 / 203
Front Fork Travel in mm	150	150	150	150
Rear Suspension Travel in mm	155	155	155	155
Battery capacity	800 Wh	800 Wh	800 Wh	800 Wh
Fitting Length in mm	230X60	230X60	230X60	230X60
