Torque 6
Trail, enduro or downhill, you choose. The Torque 6 is a versatile gravity bike that blurs the boundaries and brings big performance to serious downhill riding. It can be used for everything from hitting bike park jumps or all-day big mountain epics.
-
-
Members only product. Log in here
Select frame size
Hint: Use our recommendation and get the correct size first time.
Sold out
Members only product.
Log in here
Sold out
Highlights Torque 6

Downtube Cover with Cable Channel
The downtube cover integrates seamlessly into the frame and doesn’t just protect your bike from dings and scratches, it also functions as a rattle-silencing cable channel and makes replacing cables a simple and easy process.

Geometry
Super enduro, park bike, freeride, call it whatever you like. What matters is that the geometry of the Torque offers superior control and stability at speed, while remaining agile and playful on track and in the air.
Content is loading
Frame
-
Frame
- Canyon Torque
- Material: Aluminium (AL)
- Weight: 1,898 g
-
Rear Shock
- FOX DPX2 Performance
- Weight: 434 g
-
Suspension Fork
- FOX 38 Performance Grip
- Travel: 180 mm
- Fork steer tube diameter: 1 1/8" - 1 1/4"
- Weight: 1,200 g
Drivetrain
-
Rear Derailleur
- Shimano Deore SLX M7100
- Cage length: long
- Weight: 310 g
-
Chainguard
- e*thirteen TRS ISCG05
-
Shift Lever
- Shimano Deore SLX M7100
- Weight: 143 g
-
Cassette
- Shimano Deore SLX CS-M7100
- Number of sprockets: 12
- Range: 10-51
-
Crank
- Shimano SLX M7100 32T
- Number of chainrings: 1
-
Bottom bracket
- Shimano MT801
- Bottom bracket standard: BSA HT2 68/73
- Weight: 79 g
-
Chain
- Shimano CN-M7100 12s
Brakes
-
Disc Brake
- Shimano SLX M7120
-
Disc Brake
- Shimano SLX M7120
-
Brake Rotor
- Shimano RT70
- Size: 180 mm
- Weight: 195 g
-
Brake Rotor
- Shimano SLX rotor, 203mm
- Size: 203 mm
- Weight: 212 g
Wheels
-
Front Wheel
- RaceFace AR30
- Rotor mount: Center Lock
- Weight: 820 g
-
Rear Wheel
- RaceFace AR30 | Shimano MT410
- Rotor mount: Center Lock
- Weight: 993 g
-
Tyre
- MAXXIS Minion DHR II 2.4''
- Width: 2.4"
- Weight: 900 g
-
Tyre
- MAXXIS Minion DHR II 2.4''
- Width: 2.4"
- Weight: 1,224 g
-
Thru Axle
- Canyon GP0225-01
Cockpit
-
Stem
- Canyon G5
- Modern design, extreme durability: Canyon G5 components were developed by our pros on the world's toughest trails.
- Fork steer tube diameter: 1 1/8"
- Clamping diameter: 31,8 mm
- Material: Aluminium (AL)
-
Handlebar
- Canyon G5
- Our aluminum G5 Riser bar offers the perfect combination of width (780mm) and rise.
-
Grips
- Canyon G5
Seat
-
Saddle
- Fizik Gravita Alpaca X5
- Gender: Unisex
- Weight: 220 g
-
Seatpost
- Iridium Dropper Post
- Move more freely on steep descents, by dropping down saddle with the press of a handlebar-mounted button. With internal cabling.
- Seatpost diameter: 30,9 mm
- Material: Aluminium (AL)
- Weight: 567 g
-
Seat Clamp
- Canyon SC0001
Accessories
-
Pedals
- None included
-
Manuals and Accessories
- Canyon Organza Bag
-
Manuals and Accessories
- Canyon Assembly Paste
-
Manuals and Accessories
- Canyon Smallbox
-
Manuals and Accessories
- Canyon Torque Wrench
-
Manuals and Accessories
- Canyon Shock Pump 300 Psi
Content is loading
Content is loading
Body Height in cm
|
≤ 170 | 170 - 178 | 178 - 186 | ≥ 186 |
---|---|---|---|---|
Seat Height in mm
(a)
|
653 - 783 | 693 - 823 | 728 - 848 | 773 - 893 |
Seat Tube Length in mm
(b)
|
400 | 440 | 455 | 500 |
Top Tube Length in mm
(c)
|
597 | 620 | 642 | 665 |
Head Tube Length in mm
(d)
|
115 | 128 | 135 | 145 |
Head Tube Angle
(e)
|
65° | 65° | 65° | 65° |
Seat Tube Angle
(f)
|
74° | 74° | 74° | 74° |
Chainstay Length in mm
(g)
|
425 | 428 | 428 | 428 |
Wheel Base in mm
(h)
|
1.171 | 1.195 | 1.219 | 1.243 |
Stack in mm
(i)
|
618 | 627 | 636 | 645 |
Reach in mm
(j)
|
420 | 440 | 460 | 480 |
Stand-over Height in mm
(k)
|
759 | 761 | 762 | 776 |
Bottom Bracket Offset in mm
(l)
|
15 | 15 | 15 | 15 |
Spacer in mm
|
15,0 | 15,0 | 15,0 | 15,0 |
---|---|---|---|---|
Stem Length in mm
|
40 | 40 | 40 | 40 |
Handlebar Width in mm
|
780 | 780 | 800 | 800 |
Crank Length in mm
|
165,0 | 165,0 | 165,0 | 165,0 |
Chainring Size
|
32 | 32 | 32 | 32 |
Seat Post Diameter in mm
|
30,9 | 30,9 | 30,9 | 30,9 |
Dropper post travel in mm
|
150 | 150 | 170 | 170 |
Seat Post Length in mm
|
425 | 425 | 465 | 465 |
Maximum Seat Post Insertion Depth in mm
|
220 | 220 | 240 | 240 |
Minimum Seat Post Insertion Depth in mm
|
90 | 90 | 120 | 120 |
Wheel Size
|
27.5" | 27.5" | 27.5" | 27.5" |
Disc Size in mm
|
203 / 180 | 203 / 180 | 203 / 180 | 203 / 180 |
Front Fork Travel in mm
|
180 | 180 | 180 | 180 |
Rear Suspension Travel in mm
|
175 | 175 | 175 | 175 |
Fitting Length
|
250X70 | 250X70 | 250X70 | 250X70 |
