        Aeroad CF SLX 8 Disc eTap
-
                    -23%
4,919 US$
Original price
You save 1,480 US$


                A masterfully sculpted, watt-saving aero frame. Zipp’s incredible 404 Firecrest carbon aero wheelset. Wireless electronic shifting. This is a complete performance package built to give you every possible advantage out on the road.
















                            Members only product.




    Log in here








Additional 10% off with code "OUTLET10"
Additional information









        Current delivery times information.

        Read more














        Not included:





                        Delivery:

                            Select color







            Highlights Aeroad CF SLX 8 Disc eTap
                                    Content is loading

                            Frame
-
                                Frame- Canyon Aeroad CF SLX Disc
- Axle dimension: 12x142 mm
- Tyre clearance: 31 mm
- Material: Carbon (CF)
- Weight: 1,080 g

-
                                Fork- Canyon FK0060 CF Disc
- Aero design shaped using advanced CFD technology. Disc flat-mount disc standard. CT scanner tested and approved.
- Axle dimension: 12x100 mm
- Fork steer tube diameter: 1 1/8"
- Material: Carbon (CF)
- Weight: 330 g

Drivetrain
-
                                Battery- SRAM Powerpack

-
                                Rear Derailleur- SRAM Force eTap AXS
- Weight: 301 g

-
                                Front Derailleur- SRAM Force eTap AXS
- Weight: 162 g

-
                                Cassette- SRAM Force XG-1270, 12-speed, 10-28T
- Number of sprockets: 12

-
                                Crank- SRAM Force D1 AXS Powermeter
- Number of chainrings: 2

-
                                Bottom bracket- SRAM DUB Pressfit
- Bottom bracket standard: PF 86,5
- Weight: 67 g

-
                                Chain- SRAM FORCE D1 12-speed
- With signature flat-top design for quieter operation and increased strength and durability. And hard chrome plated inner link plates and rollers for reduced wear.

Brakes
-
                                Shift-/ Brake Lever- SRAM Force eTap AXS, 12-speed
- Weight: 472 g

-
                                Shift-/ Brake Lever- SRAM Force eTap AXS, 12-speed
- Weight: 489 g

-
                                Brake Rotor- SRAM Paceline
- Size: 160 mm
- Weight: 159 g

Wheels
-
                                Front Wheel- ZIPP 404 Firecrest
- Rotor mount: Center Lock
- Rim height: 58 mm
- Weight: 850 g

-
                                Rear Wheel- ZIPP 404 Firecrest Db
- Rim height: 58 mm
- Weight: 500 g

-
                                Tyre- Continental Grand Prix 5000 25mm
- Width: 25 mm
- Weight: 245 g

-
                                Tyre- Continental Grand Prix 5000, 28 mm
- Width: 28 mm
- Weight: 245 g

-
                                Thru Axle- DT Swiss Through Axle
- Axle dimension: 12x100 mm

-
                                Thru Axle- DT Swiss Through Axle
- Axle dimension: 12x142 mm

Cockpit
-
                                Cockpit- Canyon CP0018 Aerocockpit
- Aero design, reinforced carbon walls for added stiffness and improved durability.
- Material: Carbon (CF)
- Weight: 195 g

-
                                Handlebar Tape- Canyon Ergospeed Gel
- Grippy, durable bar tape with a premium, high-quality, comfortable feel.
- Color: black

Seat
-
                                Saddle- Selle Italia SLR Boost Superflow Titanium
- Gender: Unisex
- Max. Rider Weight: 100 kg
- Weight: 158 g

-
                                Seatpost- Canyon SP0046 Aero Seatpost
- Aero-optimised carbon seatpost with new sleeve bearing that creates a seal and reduces seatpost and seat tube friction and prevents dirt from entering.
- Clamp diameter: 27,2 mm

-
                                Seat Clamp- Canyon GP0223-02 Clamp Set 7x7

Accessories
-
                                Pedals- None included

-
                                Manuals and Accessories- Canyon Organza Bag

-
                                Manuals and Accessories- Canyon Assembly Paste

-
                                Manuals and Accessories- Canyon Torque Wrench

-
                                Manuals and Accessories- Canyon Smallbox

                                    Content is loading


                Content is loading

        |

                                                    Body Height in cm



                                             | ≤ 166 | 166 - 172 | 172 - 178 | 178 - 184 | 184 - 190 | 190 - 196 | ≥ 196 |
|---|---|---|---|---|---|---|---|
|

                                                    Seat Height in mm


                                                        (a)


                                             | 624 - 704 | 654 - 734 | 684 - 764 | 714 - 794 | 744 - 824 | 774 - 854 | 804 - 884 |
|

                                                    Seat Tube Length in mm


                                                        (b)


                                             | 443 | 473 | 503 | 533 | 563 | 593 | 623 |
|

                                                    Top Tube Length in mm


                                                        (c)


                                             | 520 | 533 | 549 | 559 | 572 | 598 | 613 |
|

                                                    Head Tube Length in mm


                                                        (d)


                                             | 86 | 109 | 126 | 147 | 167 | 193 | 211 |
|

                                                    Head Tube Angle


                                                        (e)


                                             | 70,5° | 71,5° | 72,8° | 73,3° | 73,3° | 73,5° | 73,8° |
|

                                                    Seat Tube Angle


                                                        (f)


                                             | 73,5° | 73,5° | 73,5° | 73,5° | 73,5° | 73,5° | 73,5° |
|

                                                    Chainstay Length in mm


                                                        (g)


                                             | 410 | 410 | 410 | 410 | 410 | 410 | 410 |
|

                                                    Wheel Base in mm


                                                        (h)


                                             | 971 | 976 | 983 | 988 | 1.001 | 1.024 | 1.037 |
|

                                                    Stack in mm


                                                        (i)


                                             | 498 | 521 | 539 | 560 | 580 | 606 | 624 |
|

                                                    Reach in mm


                                                        (j)


                                             | 372 | 378 | 390 | 393 | 401 | 419 | 429 |
|

                                                    Stand-over Height in mm


                                                        (k)


                                             | 733 | 759 | 785 | 810 | 834 | 860 | 884 |
|

                                                    Bottom Bracket Offset in mm


                                                        (l)


                                             | 72 | 72 | 70 | 70 | 70 | 70 | 70 |
|

                                                    Stack+ in mm



                                             | 573 | 596 | 613 | 640 | 656 | 681 | 701 |
|

                                                    Reach+ in mm



                                             | 429 | 446 | 459 | 562 | 490 | 509 | 529 |
|

                                                    Spacer in mm



                                             | 15,0 | 15,0 | 15,0 | 15,0 | 15,0 | 15,0 | 15,0 |
|---|---|---|---|---|---|---|---|
|

                                                    Cockpit Dimensions in mm



                                             | 80-390 | 90-390 | 90-390 | 100-410 | 110-410 | 110-410 | 120-410 |
|

                                                    Crank Length in mm



                                             | 165,0 | 170,0 | 172,5 | 172,5 | 175,0 | 175,0 | 175,0 |
|

                                                    Chainring Size



                                             | 50/37 | 50/37 | 50/37 | 50/37 | 50/37 | 50/37 | 50/37 |
|

                                                    Seat Post Length in mm



                                             | 335 | 335 | 335 | 335 | 335 | 335 | 335 |
|

                                                    Maximum Seat Post Insertion Depth in mm



                                             | 202 | 202 | 202 | 202 | 202 | 202 | 202 |
|

                                                    Minimum Seat Post Insertion Depth in mm



                                             | 122 | 122 | 122 | 122 | 122 | 122 | 122 |
|

                                                    Wheel Size



                                             | 28" | 28" | 28" | 28" | 28" | 28" | 28" |
|

                                                    Disc Size in mm



                                             | 140 / 140 | 160 / 160 | 160 / 160 | 160 / 160 | 160 / 160 | 160 / 160 | 160 / 160 |



                            Download PDF



                Aeroad CF SLX 8 Disc eTap support
Disclaimer
Subject to technical modification without notice. Errors and omissions excepted.
