Grizl CF SL 7
-
-
Members only product. Log in here
Highlights Grizl CF SL 7

Cockpit

Crank and chainstays

Top tube mount
Frame
-
Frame
- Canyon Grizl CF SL
- Versatile frame designed for maximum utility. Tyre clearance: 50 mm. Gravel Pro geometry for off-road stability & agility. Dropper post and suspension fork compatibility. 12 x 142 mm through axle. Weight: 925 g (size M).
-
Fork
- Canyon FK0087 CF Disc
- Axle dimension: 12x100 mm
- Fork steer tube diameter: 1 1/4"
- Tyre clearance: 54 mm
- Material: Carbon (CF)
- Weight: 398 g
Drivetrain
-
Rear Derailleur
- Shimano GRX RX810 GS
- Cage length: long
- Weight: 252 g
-
Front Derailleur
- Shimano GRX RX810
- Max chainring gear range: 17T.
- Weight: 101 g
-
Cassette
- Shimano HG700 11-34 11s
- Number of sprockets: 11
-
Crank
- Shimano RX600
- Number of chainrings: 2
-
Bottom bracket
- Token Ninja Lite BB4124
- Bottom bracket standard: PF 86,5
- Weight: 85 g
-
Chain
- Shimano HG601 11-speed
Brakes
-
Shift-/ Brake Lever
- Shimano GRX RX600, 2-speed
- Weight: 541 g
-
Shift-/ Brake Lever
- Shimano GRX RX600 11s
- Weight: 541 g
-
Brake Rotor
- Shimano RT70
- Size: 160 mm
- Weight: 150 g
Wheels
-
Front Wheel
- DT Swiss G1800 Spline db
- Rotor mount: Center Lock
- Rim height: 25 mm
- Weight: 880 g
-
Rear Wheel
- DT Swiss G1800 Spline db SH11
- Rotor mount: Center Lock
- Rim height: 25 mm
- Weight: 10 g
-
Tyre
- Maxxis Rambler 45 mm
-
Thru Axle
- Canyon GP0197-01
- Axle dimension: 12x100 mm
-
Thru Axle
- Canyon GP0235-01
- Axle dimension: 12x142 mm
Cockpit
-
Stem
- Canyon V13
- High-quality aluminium stem with square cross-sectional profile. A new handlebar clamp design increases torsional stiffness by up to 40%. Handlebar clamp diameter: 31.8 mm. Head tube diameter: 1 1/4".
- Fork steer tube diameter: 1 1/4"
- Clamping diameter: 31,8 mm
-
Handlebar
- Canyon HB 0050 Ergobar AL
- Aluminium handlebar with comfortable, ergonomically optimised design.
- Material: Aluminium
- Shape: Ergo
- Reach: 70 mm
- Drop: 130 mm
-
Handlebar Tape
- Canyon Ergospeed Gel
- Grippy, durable bar tape with a premium, high-quality, comfortable feel.
- Color: black
Seat
-
Saddle
- WTB Volt Steel
-
Seatpost
- Canyon SP0057 VCLS
- With vibration-absorbing design for top rear-end comfort.
- Setback: 20 mm
- Seatpost diameter: 27,2 mm
- Material: Carbon (CF)
- Weight: 265 g
Accessories
-
Pedals
- None included
-
Manuals and Accessories
- Canyon Organza Bag
-
Manuals and Accessories
- Canyon Assembly Paste
-
Manuals and Accessories
- DT Swiss warranty & intended use manual
-
Manuals and Accessories
- Canyon Starter Box
-
Manuals and Accessories
- Canyon Torque Wrench
-
Manuals and Accessories
- Endurace Quick Start Guide
Body Height in cm
|
≤ 166 | 166 - 172 | 172 - 178 | 178 - 184 | 184 - 189 | 189 - 194 | ≥ 194 |
---|---|---|---|---|---|---|---|
Seat Height in mm
(a)
|
623 - 723 | 653 - 753 | 683 - 783 | 713 - 813 | 743 - 843 | 773 - 873 | 803 - 903 |
Seat Tube Length in mm
(b)
|
432 | 462 | 492 | 522 | 552 | 582 | 612 |
Top Tube Length in mm
(c)
|
532 | 541 | 562 | 574 | 588 | 612 | 627 |
Head Tube Length in mm
(d)
|
121 | 133 | 118 | 138 | 164 | 185 | 204 |
Head Tube Angle
(e)
|
70° | 71° | 71° | 72,25° | 72,5° | 72,75° | 72,75° |
Seat Tube Angle
(f)
|
73,5° | 73,5° | 73,5° | 73,5° | 73,5° | 73,5° | 73,5° |
Chainstay Length in mm
(g)
|
420 | 420 | 435 | 435 | 435 | 435 | 435 |
Wheel Base in mm
(h)
|
1.007 | 1.007 | 1.036 | 1.037 | 1.050 | 1.072 | 1.086 |
Stack in mm
(i)
|
522 | 537 | 556 | 579 | 605 | 626 | 644 |
Reach in mm
(j)
|
377 | 382 | 397 | 402 | 409 | 427 | 436 |
Stand-over Height in mm
(k)
|
737 | 761 | 789 | 816 | 845 | 870 | 892 |
Bottom Bracket Offset in mm
(l)
|
60 | 60 | 75 | 75 | 75 | 75 | 75 |
Stack+ in mm
|
612 | 626 | 644 | 669 | 696 | 717 | 737 |
Reach+ in mm
|
423 | 430 | 445 | 461 | 478 | 496 | 515 |
Spacer in mm
|
27,5 | 27,5 | 27,5 | 27,5 | 27,5 | 27,5 | 27,5 |
---|---|---|---|---|---|---|---|
Stem Length in mm
|
70 | 70 | 70 | 80 | 90 | 90 | 100 |
Handlebar Width in mm
|
400 | 400 | 420 | 440 | 440 | 460 | 460 |
Crank Length in mm
|
170,0 | 170,0 | 170,0 | 172,5 | 175,0 | 175,0 | 175,0 |
Chainring Size
|
46/30 | 46/30 | 46/30 | 46/30 | 46/30 | 46/30 | 46/30 |
Seat Post Diameter in mm
|
27,2 | 27,2 | 27,2 | 27,2 | 27,2 | 27,2 | 27,2 |
Seat Post Length in mm
|
350 | 350 | 350 | 350 | 350 | 350 | 350 |
Maximum Seat Post Insertion Depth in mm
|
207 | 207 | 207 | 207 | 207 | 207 | 207 |
Minimum Seat Post Insertion Depth in mm
|
107 | 107 | 107 | 107 | 107 | 107 | 107 |
Wheel Size
|
27.5" | 27.5" | 28" | 28" | 28" | 28" | 28" |
Disc Size in mm
|
160 / 160 | 160 / 160 | 160 / 160 | 160 / 160 | 160 / 160 | 160 / 160 | 160 / 160 |
Grizl CF SL 7 support
Bike classification
Bikes of this category are designed for riding on hard-surface roads where the wheels remain in permanent contact to the ground. These are in general road racing bicycles with racing handlebars or straight handlebars, triathlon or time trial bicycles. The permissible maximum overall weight comprising rider, luggage and bicycle should not exceed 120 kg. Under certain circumstances this permissible maximum weight can be further limited by the component manufacturers’ recommendations for use. Proven cyclocross and gravel bikes with racing handlebars and cantilever or disc brakes are a special case in this category. In addition, these bikes are also suitable for gravel paths and off-road trails where a short loss of tyre contact with the ground due to small stairs or steps at a height of 15 to 20 cm can occur.
Proposition 65 Warning
Warning: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
Production Variations
We strive for complete accuracy with our technical specifications. However, specifications are subject to change without notice. Variation between posted information and actual specification does not warrant any changes, modifications, or exchanges to any products affected by a variation. If we may provide further details, please contact our Canyon USA Service Team.
