Pathlite:ON 6 SUV

2.599 €

Original price ~~3.799 €~~

You save 1.200 €

Start planning that epic all-terrain bike tour you’ve always dreamed of with this powerful, comfortable, capable e-touring bike. Ride strong all day long with powerful Bosch motor support, and a long-range 750 Wh battery. Experience incredible comfort with a shock-absorbing suspension seatpost with on-the-fly height adjustability, high-quality suspension fork, and adjustable handlebar. And don’t worry about a thing, thanks to advanced connectivity, ride tracking, and theft protection from Bosch.

Range up to: 150 km
Weight: 26.92 kg

Weight

Weight is based on a size medium frame.

Reviews (65)

Press and awards (1)

Members only product.

Select frame size

What’s my size?
Find out in 3 steps

Delivery: Select frame size

Members only product.

2.599 €

Original price ~~3.799 €~~

You save 1.200 €

Delivery: Select frame size

Select frame size

Additional information

Current delivery times information. Read more

Included:

Not included:

Shipping & Packaging

JobRad® - Your dream bike up to 40 % cheaper **

The JobRad® price is generally calculated on the maximum possible income tax benefit. Calculate your personal savings with JobRad® now!
Go to the JobRad® calculator

Leasing with Bikeleasing-Service **

Bikeleasing-Service makes it easy to lease your dream bike or e-bike, including accessories – with savings of up to 40% and theft insurance included.
Learn more

Leasing with Deutsche Dienstrad **

Save up to 40% and take advantage of tax free savings now. Choose any Canyon bike or e-bike, add the approved gear and accessories you need, then apply.
Learn more

Leasing with Business Bike **

Get up to 40% off with tax-free savings. Select your Canyon bike or e-bike, include the approved gear and accessories, and apply.

Learn more

Company Bike **

Pay monthly, save up to 45%, and take advantage of tax free savings
Learn more

* The leasing price is generally calculated on the basis of the maximum possible income tax benefit. The savings or leasing rate that applies to you depends on your income and personal circumstances and may be lower. Please consult a tax advisor.

** The rate is calculated using the original cost of the bike.
Financing with Consors Finanz

Spread the payments on your bike and gear with Consors Finanz
Calculate amount

Financing with PayPal

Financing with Klarna Instalments

Klarna offers direct payments, pay later options, or installment plans
Calculate amount
Stress free New Bike Day

Our most premium service. Collect your new bike directly from Canyon, fully assembled and set up by a Canyon mechanic. They will answer any questions and ensure you're ready to ride.

How to choose New Bike Day

Collect & Ride

Nervous about building your new bike? Have your bike sent directly to your local bike shop to be assembled by an expert. Collect your bike at a time that suits you.

How to choose Collect & Ride
Your bike already arrives 95% built. We give you the tools. And simple instructions. No technical skills needed.
That’s our quality promise – if you’re not 100% happy with your bike, we’re not happy either.
Learn more

Delivery: Select frame size

Highlights Pathlite:ON 6 SUV

This is Pathlite:ON SUV

All power, most powerful Bosch motor

With great power comes great responsibility and our engineers have stepped up to the task, creating an e-touring bike that’s as easy to ride as it is rugged and powerful. So while the Pathlite:ON SUV boasts huge hauling power, a powerful motor and terrain-taming features it refuses to compromise when it comes to all day comfort and outright enjoyment.

Pack your bike for day adventure

There’s no need to pack light when touring with the Pathlite:ON SUV. Bottle mounts, an integrated rack and secure pannier bags give you mountains of storage for days out in the hills. Add the compatible trailer (sold separately) to gain up to 50 extra kilos of kit, snacks and even the dog to make the great outdoors better than ever.

Key features

A powerful long-range motor with advanced theft protection

The Bosch Performance Line CX and Smart System has a huge 340% pedal assistance with 85 Nm of torque for a punchy, powerful feel. And with the 750 Wh battery, there's loads of juice for long rides and steep climbs. Link the system with your smartphone for additional perks like the Bosch e-Bike Alarm security system with advanced GPS location tracking.

An easy-to-charge, easy-to-remove battery

The Pathlite:ON’s battery is perfectly integrated into the downtube. It's also incredibly easy to charge. Or just pop it out, take it into the office, and plug in the charger included with your bike.

Bright, reliable Supernova lighting

Feel safe in the darkest, wettest conditions, even on your early morning commute in winter. The bike’s front light is powered by the bike’s main battery, and its high-beam function is mega bright and easy to control from the handlebar.

Powerful, precise braking

Low weight, low maintenance, high performance: these high-grade Magura brakes give you powerful, reliable stopping power. Year after year, in all weather conditions. Thanks to their precise modulation, you get plenty control in all situations. And the ergonomic grips give you a safe and secure, hold on the bar when you need it most.

Sharp gear shifting come rain or shine

Proven performance, year-in-year-out reliability. Shimano’s legendary XT groupset provides sharp shifting, year after year, in all weather conditions. The latest Hyperglide+ technology makes shifting even faster, and the drivetrain is quieter thanks to decreased rear derailleur and chain tension.

Components

Content is loading

Frame

Frame
- Canyon Pathlite:ON
- A tough, feature-packed aluminium e-touring bike frame with a comfortable riding position.
- Axle dimension: 12x148 mm
- Material: Aluminium (AL)
- Weight: 1,250 g
Suspension Fork
- FS SUT XCR34 27.5 100 AIR 15X110 C74 1.5
- Axle dimension: 15x110 mm
- Travel: 100 mm
- Fork steer tube diameter: 1 1/8" - 1,5"

Drivetrain

Motor
- Bosch Performance Line CX
Battery
- Bosch PowerTube 750Wh
Rear Derailleur
- Shimano Deore XT M8100
- Cage length: long
- Weight: 248 g
Shift Lever
- Shimano Deore M6100, 12-Speed
- Weight: 136 g
Cassette
- Shimano Deore M6100
- Number of sprockets: 12
- Range: 10-51
Crank
- FSA CK 220
- Number of chainrings: 1
Chainring
- FSA 42T Chainring with Guard
Chain
- Shimano Deore M6100

Brakes

Disc Brake
- Magura MT30 hydraulic disc brake
- Number of pistons: 4
Disc Brake
- Magura MT Thirty
- Number of pistons: 2
Brake Rotor
- Magura MDR-C
- Size: 180 mm
- Weight: 138 g

Wheels

Front Wheel
- Alexrims MD25 | Promax DR850
- Axle dimension: 15x110 mm
- Rotor mount: Center Lock
- Rim height: 20 mm
- Inner width: 25 mm
- Rim material: Aluminium
- Weight: 905 g
Rear Wheel
- Alexrims MD25 | Promax DR850 SH12
- Axle dimension: 12x148 mm
- Rotor mount: Center Lock
- Rim height: 20 mm
- Inner width: 25 mm
- Rim material: Aluminium
- Weight: 950 g
Tyre
- Maxxis Crossmark II Reflexstrip Clincher
- Width: 2,25"
- Weight: 750 g
Thru Axle
- Canyon GP0420 Rear Thru Axle
- Axle dimension: 12x148 mm

Cockpit

Stem
- Canyon ST0036 Adjustable
- Fork steer tube diameter: 1 1/8"
- Clamping diameter: 31,8 mm
Handlebar
- Iridium Flatbar
- Clamping diameter: 31,8 mm
- Rise: 5 mm
Grips
- Ergon GA3
Bells
- Knog Oi Classic
Display
- Bosch Purion 200 Display BRC3800

Seat

Saddle
- Selle Royal Essenza+ Athletic
- Gender: Unisex
- Weight: 420 g
Seatpost
- Canyon SP0062 Supension Dropper Post
- Seatpost diameter: 30,9 mm
- Material: Aluminium (AL)
- Weight: 518 g
Seat Clamp
- Canyon GP0170-01 Seatclamp

Light

Lights
- Supernova Mini 2 Pro Frontlight
Lights
- Sate-Lite M12 Rear Light

Accessories

Battery Charger
- Bosch 4A
Pedals
- VP-536 f
Bike Racks
- Canyon Rack
Fender
- Plastic mudguards
Fender
- FEND GP0405-02 27.5 FRONT w/STAYS bk
Fender
- Canyon GP0563-01 Fender Kit
Manuals and Accessories
- Canyon Organza Bag
Manuals and Accessories
- Wrench Tool 15mm
Manuals and Accessories
- Canyon Assembly Paste
Manuals and Accessories
- Canyon Torque Wrench
Manuals and Accessories
- Quick Start Guide
Manuals and Accessories
- Canyon Shock Pump 300 Psi
Manuals and Accessories
- CAYN SMALL BOX 2.0

Content is loading

Geometry & dimensions

Basic geometry

Detailed geometry table

Body Height in cm	≤ 180	180 - 190	≥ 190
Seat Height in mm (a)	633 - 813	678 - 858	723 - 903
Seat Tube Length in mm (b)	430	475	520
Top Tube Length in mm (c)	598	625	652
Head Tube Length in mm (d)	137	164	191
Head Tube Angle (e)	68,5°	68,5°	68,5°
Seat Tube Angle (f)	73,5°	73,5°	73,5°
Chainstay Length in mm (g)	460	460	460
Wheel Base in mm (h)	1.138	1.168	1.198
Stack in mm (i)	650	675	700
Reach in mm (j)	405	425	445
Stand-over Height in mm (k)	775	800	825
Bottom Bracket Offset in mm (l)	65	65	65

Component geometry

Detailed geometry table

Spacer in mm	10,0	10,0	10,0
Stem Length in mm	65	65	65
Handlebar Width in mm	680	680	680
Crank Length in mm	170,0	170,0	170,0
Seat Post Diameter in mm	30,9	30,9	30,9
Dropper post travel in mm	25	25	25
Seat Post Length in mm	415	415	415
Maximum Seat Post Insertion Depth in mm	260	260	260
Minimum Seat Post Insertion Depth in mm	80	80	80
Wheel Size	27.5"	27.5"	27.5"
Disc Size in mm	180 / 180	180 / 180	180 / 180
Front Fork Travel in mm	100	100	100
Battery capacity	750 Wh	750 Wh	750 Wh

Download PDF

Press and awards

2024

Value Tipp

An agile, intelligently designed all-rounder with the added comfort of a suspension fork and great touring features. A brilliant bike at a brilliant price.

Value Tipp

An agile, intelligently designed all-rounder with the added comfort of a suspension fork and great touring features. A brilliant bike at a brilliant price.

Content is loading

Pathlite:ON 6 SUV support

Bike classification

Bikes of category 2e are suitable for well-maintained hard-surface roads where the wheels remain in permanent contact to the ground. These bikes are designed for urban mobility and thus mainly for participation in road traffic and use on public and permitted lanes. This category comprises urban, city bikes and trekking bikes. The permissible maximum overall weight comprising rider, luggage and bicycle is mentioned on the CE marking on your bike. The E-Bike specific information is mentioned on the separate CE marking.
Bikes in this category provide motorised support up to 25 kph. You can ride above 25 kph, just without support.

Disclaimer

Subject to technical modification without notice. Errors and omissions excepted.
